Case 1150G Crawler

The Case 1150G is a model in the Case Crawler Tractor series. The engine delivers 125.7 hp (88.7 kW), has 6 cylinders, with a displacement of 5,901 cm³. The engine comes from Case. Torque is 504.4 Nm. Rated speed is 2,000 rpm. Ground clearance is 329.2 mm. The tank holds 212.4 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,600 rpm. The pump delivers 126.1 l/min. Working pressure is 172.4 bar. The cooling system holds 24.6 litres. The oil fill is 15.1 litres. The electrical system runs on 12 V. The engine fitted is the 6T-590. The Case Crawler Tractor series covers 51 models. Rated output within it ranges from 74.8 to 588 hp; the 1150G sits at the bottom of that range with 125.7 hp. Its immediate neighbours are the 850L XLT below it with 100.7 hp and the 1150B above it with 126.7 hp. 620 Case models across 22 series are on record. The model is listed under Mining equipment. 19 verified figures from 1 source are on file.
