Web Trailer N/A – specifications
Built: 2012–2026 · Series: Other models
Data for the version built 2012–2026 · Data origin: Official register · sources
More machines from model year 2012
Web Trailer – other models: the collective page of heavy semi-trailers from the Dutch manufacturer outside the named ranges, gross weight from 12,000 to 48,000 kg, widths up to 2,600 mm
This page gathers semi-trailers of the Dutch brand Web Trailer that the register could not assign to a named range. Web Trailer is one of the Dutch semi-trailer builders for heavy road haulage; type codes such as PRSH, PRSGR or PRAF in the holdings evidently combine the body type (curtain, system trailer) with the axle count and range, while the suffixes TRI or MEGA denote Trilex wheels or mega semi-trailers with increased load space.
Read on 4 more paragraphs
The register lists here 116 versions with unladen weights from 2,630 to 13,580 kg, gross weights from 12,000 to 48,000 kg, lengths from 5,850 to 14,040 mm and widths from 2,500 to 2,600 mm.
With gross weights consistently above 12 tonnes and widths close to the European maximum of 2,550 mm, Web Trailer sits clearly in the segment of standard three-axle semi-trailers for long-haul transport, comparable with Pacton, Groenewegen or Kögel.
As class O4 semi-trailers, these types consistently need an air brake system and driving licence category CE for towing; the connection to the tractor unit runs through a fifth-wheel coupling and kingpin. Dolly combinations fit a body actually built as a semi-trailer with an additional towing eye, so it can also be pulled by a vehicle without a fifth wheel.
When buying used, what counts is the condition of the frame and chassis rails (rust, weld cracks), axles and braking system (ABS/EBS, drum or disc), the condition of the curtain including its roll or sliding roof mechanism, the operation of the landing legs and kingpin, and complete inspection records; on dolly combinations, additionally the condition of the tow eye and coupling.
Sources: SpecCodex register, model data: Web Trailer
Technical data
Dimensions and weights
| Length | 14,040 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Coupling-to-axle distance | 11,470 mmcorrect |
| Unladen weight | 13,100 kgcorrect |
| Gross vehicle weight | 45,000 kgcorrect |
Drivetrain and chassis
| Wheels | 8correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Web Trailer N/A weigh?
The unladen weight is 13,100 kg.
What is the gross vehicle weight of the Web Trailer N/A?
45,000 kg.
Up to what speed is the Web Trailer N/A approved?
Approved up to 100 km/h.
What are the dimensions of the Web Trailer N/A?
14,040 mm × 2,600 mm.
When was the Web Trailer N/A built?
Production years: 2012–2026.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
