Ajk N/A – specifications
Built: 2013–2026 · Series: Other models
Data for the version built 2013–2026 · Data origin: Official register · sources
More machines from model year 2013
Ajk – other models: the collective page of heavy O4-class semi-trailers outside the named ranges, 20 to 47 tonnes gross weight, 3,440 to 13,840 kg unladen weight, 8,620 to 11,770 mm long
This page gathers the Ajk trailers the register could not assign to a named range. With gross weights from 20 to 47 tonnes, these are heavy O4-class semi-trailers; one model is named explicitly Auflieger-Kipper (tipping semi-trailer). The type codes AE, AET and OP mark different build lines, supplemented by number pairs for payload and axle count and the tyre size (around 22.5 inches); the R in designations such as AETLR marks a further chassis variant of the line.
Read on 3 more paragraphs
The register lists here 28 versions with unladen weights from 3,440 to 13,840 kg, gross weights from 20,000 to 47,000 kg, widths from 2,450 to 2,550 mm and lengths from 8,620 to 11,770 mm.
Tipping semi-trailers of this weight class are used for hauling building materials, excavated earth and recycling loads, competing with ranges from makers such as Meiller, Fliegl and Carnehl; the span from 20 to 47 tonnes gross weight covers both two-axle and multi-axle versions for heavy-duty use.
On a used example, the condition of the tipping body and its seals, the function of the tipping ram and hydraulics, axles, brakes and tyres, the frame for cracks and wear at the bearings, and the underrun guard and lighting system count, along with the condition of the mudguards; spare parts run through the specialist commercial-vehicle trade.
Sources: SpecCodex register, model data: Ajk (weitere Modelle)
Technical data
Dimensions and weights
| Length | 11,770 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Coupling-to-axle distance | 8,650 mmcorrect |
| Unladen weight | 13,840 kgcorrect |
| Gross vehicle weight | 47,000 kgcorrect |
Drivetrain and chassis
| Wheels | 12correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Ajk N/A weigh?
The unladen weight is 13,840 kg.
What is the gross vehicle weight of the Ajk N/A?
47,000 kg.
Up to what speed is the Ajk N/A approved?
Approved up to 100 km/h.
What are the dimensions of the Ajk N/A?
11,770 mm × 2,550 mm.
When was the Ajk N/A built?
Production years: 2013–2026.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
