Arçelik Q2EPA132M4C40-EP – a three-phase industrial motor rated at 7.5 kilowatts from the Turkish appliance maker, used for pumps and compressors
Arçelik is a Turkish manufacturer best known for household appliances such as refrigerators and washing machines, and as part of that production also makes electrical components and drives. The type described here, the Q2EPA132M4C40-EP, falls within the field of three-phase industrial motors used for pumps, fans and small machine drives.
Read on 3 more paragraphs
At a rated output of 7.5 kilowatts, the motor sits in the mid power range typical of centrifugal pumps, compressors or smaller machine tools. The figure 132 in the type designation corresponds to a common frame size under IEC 60072 and fixes the shaft centre height together with the foot and flange mounting dimensions.
In industrial motors of this kind the squirrel-cage rotor is standard, since it runs with little maintenance and needs no slip rings. The number of poles sets the synchronous speed: at 50 hertz, two-pole motors turn at 3,000 revolutions per minute, four-pole motors at 1,500 and six-pole motors at 1,000, each slightly reduced by slip. Protection ratings follow IEC 60529 and mounting arrangements IEC 60034-7, for example a foot-mounted IM B3 motor or a flange-mounted IM B5 type. Running it from a frequency inverter raises the demands on insulation strength.
When buying secondhand, the rating plate is worth checking first: output, voltage, frequency and connection type should be legible and suitable. Turned by hand, the bearings should run smoothly, without play or noise, while an insulation test with an insulation-resistance tester reveals damp or damaged windings. The fan cover and terminal box deserve a second look, since corrosion or broken ribs point to a hard working life. If the motor has been rewound, that is worth raising openly before buying.
Sources: SpecCodex-Register: Kennwerte des Modells Q2EPA132M4C40-EP
Technical data
Engine
| Rated output | 7.5 kWcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP41correct |
| Frame size | 132 M (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 89.1 %correct |
| Efficiency at 75 % load | 88.9 %correct |
| Efficiency at half load | 87 %correct |
Origin and approval
| Country of manufacture | Turkeycorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Arcelik Q2EPA132M4C40-EP have?
The Arcelik Q2EPA132M4C40-EP delivers 7.5 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
