Antonio Carraro 625
Built: approx. 1970 · Series: Supertigre
More machines from model year 1970
Antonio Carraro Supertigre – articulated specialist tractors from Campodarsego near Padua for orchards, vineyards and special crops: two-cylinder diesel engines of 18.5 to 30 hp, 950 to 990 kg
Since the 1960s Antonio Carraro has built narrow, articulated specialist tractors at Campodarsego near Padua for work in orchards, vineyards and special crops, where narrow row spacing and steep slopes call for a vehicle with a tight turning circle and a low centre of gravity. The Supertigre line spans several model generations, from the early 625 and 635 to the later Supertigre 4300, 5400, 5800, 650, 835 and 850; the numbers in the type designations do not follow one consistent system across the model years. What the models share is articulated steering, which, unlike conventional front-axle steering, drives both axles and gives the tractor high manoeuvrability in row crops and on narrow terraces.
Read on 3 more paragraphs
The register lists here 2 versions with 18.5 to 30 hp from water-cooled two-cylinder diesel engines of 1,346 cm³ at 3,000 rpm, weights of around 950 to 990 kg, a length of 2,470 mm, a width of 1,100 mm and a height to the top of the steering wheel of 1,120 mm.
With this compact format and articulated steering, Antonio Carraro occupies a niche barely served by the large tractor groups; its competitors are mainly other Italian specialists in special-crop machinery such as Goldoni and BCS. Sales concentrate on the intensive growing areas of northern Italy and on wine and fruit-growing regions across Europe.
Buying one used, the articulation joint itself deserves particular attention: play in the joint bearings and the condition of the steering cylinders determine safety on slopes. On top of that come the usual checks for compact diesel tractors – clutch, hydraulic seals, PTO and rust on the narrow cab or roll bar. Spare parts run through the Italian farm-machinery trade and the manufacturer itself, which has kept the Supertigre line supported for decades.
Sources: SpecCodex register, model data: Antonio Carraro Supertigre, Antonio Carraro
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 18.5 hpcorrect |
| Power | 18.5 hpcorrect |
| Rated speed | 3,000 rpmcorrect |
| Cylinders | 2correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 2,470 mmcorrect |
|---|---|
| Width | 1,100 mmcorrect |
| Height | 1,120 mm (to steering wheel)correct |
| Wheelbase | 1,170 mmcorrect |
| Ground clearance | ca. 250 mmcorrect |
| Unladen weight | 950 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 3-Gang, 3 Gruppen (langsam, schnell, rückwärts)correct |
| Front tyres | von 5.50-16" bis 7.50-16"correct |
| Rear tyres | von 5.50-16" bis 7.50-16"correct |
| Top speed | 20 km/hcorrect |
Other data
| Linkage category | Cat Icorrect |
|---|
Where this model stands
Power-to-weight ratio: 14.3 kW/t (14 kW / 0.9 t)
Power class: Compact (< 40 hp)
Stronger than 6% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Antonio Carraro 625 have?
The Antonio Carraro 625 delivers 18.5 hp.
How much does the Antonio Carraro 625 weigh?
The unladen weight is 950 kg.
What engine does the Antonio Carraro 625 have?
2 cylinders, Diesel.
How fast does the Antonio Carraro 625 go?
Top speed is 20 km/h.
What are the dimensions of the Antonio Carraro 625?
2,470 mm × 1,100 mm × 1,120 mm.
When was the Antonio Carraro 625 built?
Production years: ca. 1970.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
