Ameritrail GN26-202D2
Built: 2007-2007 · Series: Other models
More machines from model year 2007
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ameritrail – trailers (further models): American gooseneck trailers, 5.5 to 7.25 tonnes gross weight, up to 11 metres long
Ameritrail is listed as a manufacturer of gooseneck trailers, that is, trailers with the hitch mounted over the tow vehicle's rear axle, widely used in North America for carrying boats and machinery. This page collects the versions GN 16/20, GN16-20 and GN26-202D2.
Read on 3 more paragraphs
The register lists 3 versions with kerb weights from 2,150 to 2,950 kg, gross weights from 5,500 to 7,250 kg, lengths from 7,720 to 11,010 mm and widths from 2,180 to 2,550 mm. The range spans from a more compact to a very long gooseneck trailer.
Gooseneck trailers of this size carry larger boats, construction machinery or vehicles and, through the hitch positioned over the rear axle, offer better weight distribution and manoeuvrability than classic ball-hitch trailers. This body style is mainly established in the USA and Canada.
When buying used, check the condition of the frame and gooseneck coupling, the operation of the brakes, the condition of axles and tyres, and, on boat trailers, corrosion of the frame and rollers from saltwater exposure. Parts for axles, brakes and the coupling are available through the North American trailer trade.
Technical data
Dimensions and weights
| Length | 11,010 mmcorrect |
|---|---|
| Width | 2,260 mmcorrect |
| Wheelbase | 8,100 mmcorrect |
| Unladen weight | 2,950 kgcorrect |
| Gross vehicle weight | 7,000 kgcorrect |
Drivetrain and chassis
| Wheels | 8correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Ameritrail GN26-202D2 weigh?
The unladen weight is 2,950 kg.
What is the gross vehicle weight of the Ameritrail GN26-202D2?
7,000 kg.
Up to what speed is the Ameritrail GN26-202D2 approved?
Approved up to 100 km/h.
What are the dimensions of the Ameritrail GN26-202D2?
11,010 mm × 2,260 mm.
When was the Ameritrail GN26-202D2 built?
Production years: 2007.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
