Allis Gleaner Corporation 8360
Built: 1995–2001 · Series: AgcoStar - Serie
More machines from model year 1995
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
AGCO AgcoStar series – articulated big tractors of the 1990s: six-cylinders with 242.7 to 318.5 kW, 14,016 cm³ displacement, 13,281 to 13,373 kg unladen weight, 1,604 to 1,983 Nm torque
On its founding in 1990, AGCO Corporation first traded as Allis-Gleaner Corporation, a name derived from the acquired Allis-Chalmers Gleaner combine line, before the group was renamed AGCO Corporation shortly afterwards. Under the AgcoStar brand, AGCO built large articulated four-wheel-drive tractors for arable work in the 1990s.
Read on 3 more paragraphs
The register lists here 2 versions with 242.7 to 318.5 kW from six-cylinders of 14,016 cm³ displacement, unladen weights from 13,281 to 13,373 kg, a length of 6,919 mm, a width of 3,884 mm, a height of 3,383 mm, and torque of 1,604 to 1,983 Nm at 2,100 rpm.
With articulated steering and four-wheel drive, the AgcoStar tractors targeted large North American arable farms that needed high pulling power for tillage and seeding, and competed directly with the articulated big tractors of Case IH Steiger and John Deere. After the turn of the millennium AGCO replaced the AgcoStar range with the Challenger brand acquired from Caterpillar for articulated big tractors.
On used AgcoStar tractors, condition of the articulation joint and driveshafts, tightness and shift behaviour of the gearbox, condition of injection pump and turbocharger, and tyre and rim condition count; parts run through the AGCO parts trade. and the condition of the electrics and lighting. and the seat suspension.
Sources: SpecCodex register, model data: AGCO AgcoStar-Serie, AGCO Corporation (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 330 hp (242.7 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Torque | 1,604 Nmcorrect |
| Speed at max. torque | 1,300 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 14,016 cm³correct |
| Bore | 139.7 mmcorrect |
| Stroke | 152.4 mmcorrect |
| Compression ratio | 18.5correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 6,919 mmcorrect |
|---|---|
| Width | 3,884 mmcorrect |
| Height | 3,383 mmcorrect |
| Wheelbase | 3,482 mmcorrect |
| Ground clearance | 521 mmcorrect |
| Unladen weight | 13,281 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 18 V/2 Rcorrect |
| Front tyres | 20.8 R 42 AScorrect |
| Rear tyres | 20.8 R 42 AScorrect |
| Top speed | 40 km/hcorrect |
Origin and approval
| Construction | articulated framecorrect |
|---|
Where this model stands
Power-to-weight ratio: 18.3 kW/t (243 kW / 13.3 t)
Power class: Heavy (> 180 hp)
Stronger than 98% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Allis Gleaner Corporation 8360 have?
The Allis Gleaner Corporation 8360 delivers 330 hp.
How much does the Allis Gleaner Corporation 8360 weigh?
The unladen weight is 13,281 kg.
What engine does the Allis Gleaner Corporation 8360 have?
6 cylinders, 14,016 cm³ displacement, Diesel.
How fast does the Allis Gleaner Corporation 8360 go?
Top speed is 40 km/h.
What are the dimensions of the Allis Gleaner Corporation 8360?
6,919 mm × 3,884 mm × 3,383 mm.
When was the Allis Gleaner Corporation 8360 built?
Production years: 1995–2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
