Allis Chalmers RUMELY-DoAll
Built: 1928–1931 · Series: RUMELY-Serie
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Allis-Chalmers Rumely (6 A, DoAll) – the legacy of the 1931 Advance-Rumely takeover: 12.1 to 25 kW, 2,838 to 6,625 cm³ displacement, petrol engines
The Advance-Rumely Thresher Company of La Porte, Indiana, was known for its kerosene-fuelled OilPull tractors, but ran into financial difficulty during the Great Depression and was taken over by Allis-Chalmers in 1931. The DoAll, a general-purpose tractor with a narrow front axle for row-crop work introduced in 1928, was among the models Allis-Chalmers briefly continued under its own name after the takeover.
Read on 3 more paragraphs
The register lists here 2 versions with 12.1 to 25 kW from four- to six-cylinders of 2,838 to 6,625 cm³ displacement, unladen weights from 1,679 to 2,889 kg, a length of 2,743 to 4,140 mm, a width of 1,524 to 1,778 mm, a height of 1,505 to 1,880 mm, and rated speeds of 1,365 to 1,400 rpm; the fuel given throughout is petrol.
By taking over Rumely, Allis-Chalmers secured additional market share in the American tractor business in the early 1930s and, with the DoAll concept, took on an early answer to the emerging narrow-front-axle row-crop tractors that International Harvester had already established with the Farmall.
On these historic used Rumely models, condition of cylinders and carburettor, tightness of the fuel and cooling systems, condition of the narrow front axle and its bearings, and rust on frame and wheels count; parts can practically only be sourced through specialist collectors and vintage clubs.
Sources: SpecCodex register, model data: Allis-Chalmers Rumely-Serie
Technical data
Engine
| Fuel | petrolcorrect |
|---|---|
| Power | 16.5 hp (12.1 kW)correct |
| Rated speed | 1,400 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 2,838 cm³correct |
| Bore | 88.9 mmcorrect |
| Stroke | 114.3 mmcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,743 mmcorrect |
|---|---|
| Width | 1,524 mmcorrect |
| Height | 1,505 mmcorrect |
| Wheelbase | 1,535 mmcorrect |
| Unladen weight | 1,679 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 2 V/1 Rcorrect |
| Front tyres | 660 x 127correct |
| Rear tyres | 1.067 x 178correct |
| Top speed | 6 km/hcorrect |
Origin and approval
| Construction | frame constructioncorrect |
|---|---|
| Units built | 3,193correct |
Where this model stands
Power-to-weight ratio: 7.2 kW/t (12 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 5% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Allis Chalmers RUMELY-DoAll have?
The Allis Chalmers RUMELY-DoAll delivers 16.5 hp.
How much does the Allis Chalmers RUMELY-DoAll weigh?
The unladen weight is 1,679 kg.
What engine does the Allis Chalmers RUMELY-DoAll have?
4 cylinders, 2,838 cm³ displacement, Benzin.
How fast does the Allis Chalmers RUMELY-DoAll go?
Top speed is 6 km/h.
What are the dimensions of the Allis Chalmers RUMELY-DoAll?
2,743 mm × 1,524 mm × 1,505 mm.
When was the Allis Chalmers RUMELY-DoAll built?
Production years: 1928–1931.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
