Agrifull A-70 DL
Built: 1993–1995 · Series: DL-Serie
More machines from model year 1993
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Agrifull DL series – A-65 DL to A-90 DL-Turbo: the Italian four-cylinder field tractors of the Fiat group from the 1970s to 1990s, 48 to 63 kW
Agrifull was an Italian tractor brand belonging to the Fiat group that built field tractors from the 1970s into the 1990s. The DL series comprises four four-cylinder diesel models from the A-65 DL to the A-90 DL-Turbo, with the type number giving the approximate power step in hp and the Turbo suffix marking the turbocharged top version of the range.
Read on 3 more paragraphs
The register lists here 4 versions with 47.8 to 62.5 kW from four-cylinders of 3,613 to 3,908 cm³ displacement, unladen weights from 2,950 to 3,130 kg, lengths from 3,410 to 3,550 mm, a width of 1,970 mm and heights from 2,525 to 2,600 mm, with a rated speed of 2,500 rpm – all with diesel engines.
Agrifull tractors were mainly common in the Italian and southern European market, where they stood as versatile yard-and-field tractors of medium power class alongside the bigger Fiat and Fiatagri models and competed with other Italian brands such as Same and Lamborghini, for instance in orchards, vineyards and classic field work.
Used, the DL series calls for checking engine condition and the injection system, on the Turbo version also the turbocharger, clutch and transmission, hydraulics and PTO, and front axle and steering; corrosion on mudguards and sheet metal is a common issue on the older vintages. Spare parts now run through the independent farm machinery trade and Fiat's successors.
Sources: SpecCodex register, model data: Agrifull DL-Serie
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 70 hp (51.5 kW)correct |
| Rated speed | 2,500 rpmcorrect |
| Torque | 224 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,613 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 115 mmcorrect |
| Compression ratio | 17correct |
| Injection pressure | 230 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,550 mmcorrect |
|---|---|
| Width | 1,970 mmcorrect |
| Height | 2,600 mmcorrect |
| Wheelbase | 2,340 mmcorrect |
| Ground clearance | 505 mmcorrect |
| Unladen weight | 3,050 kgcorrect |
Drivetrain and chassis
| Drive | rear- and four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/12 R and 20 V/12 Rcorrect |
| Front tyres | 9.00-16 ASF (DT: 320/70 R 24 AS)correct |
| Rear tyres | 480/70 R 34 AScorrect |
| Top speed | 30 km/hcorrect |
Working data
| Fuel tank capacity | 93 lcorrect |
|---|
Origin and approval
| Construction | frame constructioncorrect |
|---|
Other data
| Linkage category | Cat II/Icorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 16.9 kW/t (52 kW / 3 t)
Power class: Universal (40–100 hp)
Stronger than 48% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Agrifull A-70 DL have?
The Agrifull A-70 DL delivers 70 hp.
How much does the Agrifull A-70 DL weigh?
The unladen weight is 3,050 kg.
What engine does the Agrifull A-70 DL have?
4 cylinders, 3,613 cm³ displacement, Diesel.
How fast does the Agrifull A-70 DL go?
Top speed is 30 km/h.
What are the dimensions of the Agrifull A-70 DL?
3,550 mm × 1,970 mm × 2,600 mm.
When was the Agrifull A-70 DL built?
Production years: 1993–1995.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 29 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
