Agrifull 230-C (CL/CLL)
Series: 200 er C - Baureihe
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Agrifull 200 C series (230-C, 235-C) – narrow-track two-cylinder tractors from the Fiat group: 22.1 to 25 kW, 1,348 to 1,432 cm³ displacement, 800 mm width
Agrifull was a tractor brand of the Italian Fiat group for narrow-track specialist tractors, used above all in viticulture and orcharding between narrow rows. The 200 C series with the 230-C and 235-C models and the CL and CLL versions formed the small, particularly narrow class within it, with a two-cylinder engine.
Read on 3 more paragraphs
The register lists here 2 versions with 22.1 to 25 kW from two-cylinders of 1,348 to 1,432 cm³ displacement, an unladen weight of 1,600 kg, a length of 2,100 mm, a width of 800 mm, a height of 930 mm, and a rated speed of 2,600 rpm.
With their narrow track and low build the Agrifull 200 models were designed for work between vine rows and in orchards, where conventional wide standard tractors have no room, and there competed with the narrow-track tractors of other Italian and German makers. Narrow-track tractors of this kind remain a sought-after working tool in Italian wine regions such as Piedmont and Tuscany for row-crop work to this day.
On used Agrifull 200s, condition of injection pump and clutch, tightness of the gearbox, condition of the front axle and steering, and rust on the mudguards, which take particular strain in row-crop work on narrow-track tractors, count; parts run through dealers specialising in Fiat/Agrifull. and the condition of the lighting. and the seat mounting.
Sources: SpecCodex register, model data: Agrifull 200er C-Baureihe
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 30 hp (22.1 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 1,348 cm³correct |
| Bore | 95 mmcorrect |
| Stroke | 95 mmcorrect |
| Compression ratio | 18correct |
| Injection pressure | 176 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,100 mmcorrect |
|---|---|
| Width | 800 mmcorrect |
| Height | 930 mmcorrect |
| Wheelbase | 1,050 mmcorrect |
| Ground clearance | 270 mmcorrect |
| Unladen weight | 1,600 kgcorrect |
Drivetrain and chassis
| Drive | chain drivecorrect |
|---|---|
| Gearbox | 5 V/4 Rcorrect |
| Front tyres | 200correct |
| Rear tyres | 200correct |
| Top speed | 10 km/hcorrect |
Origin and approval
| Construction | frame constructioncorrect |
|---|
Where this model stands
Power-to-weight ratio: 13.8 kW/t (22 kW / 1.6 t)
Power class: Compact (< 40 hp)
Stronger than 17% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Agrifull 230-C (CL/CLL) have?
The Agrifull 230-C (CL/CLL) delivers 30 hp.
How much does the Agrifull 230-C (CL/CLL) weigh?
The unladen weight is 1,600 kg.
What engine does the Agrifull 230-C (CL/CLL) have?
2 cylinders, 1,348 cm³ displacement, Diesel.
How fast does the Agrifull 230-C (CL/CLL) go?
Top speed is 10 km/h.
What are the dimensions of the Agrifull 230-C (CL/CLL)?
2,100 mm × 800 mm × 930 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 23 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
