AGCO Massey Ferguson MF 4220 (A)
Built: 1997–2001 · Series: 4200er-Baureihe
More machines from model year 1997
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Massey Ferguson 4200 Series – Utility Tractor, 1997 to 2001, with Three- to Six-Cylinder Engines, 38.3 to 81 kW/52 to 110 hp and Operating Weight from 2,385 to 3,880 kg
The 4200 series was the predecessor of the 4300 series and was built from 1997 to 2001. According to the register, output of the recorded models ranges from 38.3 to 81 kW, using three- to six-cylinder engines with displacement from 2,500 to 5,987 cm³.
Read on 4 more paragraphs
Recorded operating weight runs from 2,385 to 3,880 kg, wheelbase from 2,130 to 2,609 mm, and top speed of the listed models is 30 km/h.
The 4200 series targeted smaller and medium farms and was replaced in 2001 by the technically updated 4300 series. For a used model, the exact engine matters most, as the series ranged from compact three-cylinder to larger six-cylinder models.
With rated outputs from 38 to 81 kW, the 4200 series fell within the ISO 730 Category II range for the rear three-point hitch, complemented by a standard dual-speed power take-off at 540 and 1,000 revolutions per minute. Engines from the 1997 to 2001 production years predated the emissions stages with exhaust gas recirculation, particulate filters and SCR technology that shaped later tractor generations in this class.
In farming practice the series, fitted with front and rear implements, mowers and light tillage equipment, covered the daily work of smaller and medium farms. Massey Ferguson remains part of the AGCO group today, so spare parts for the engine, gearbox and hydraulics of this series run through the existing AGCO parts network.
Sources: SpecCodex register, model data: Massey Ferguson 4200er-Baureihe, Massey Ferguson
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 60 hp (44.2 kW)correct |
| Rated speed | 2,250 rpmcorrect |
| Torque | 223 Nmcorrect |
| Speed at max. torque | 1,402 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,500 cm³correct |
| Bore | 91.44 mmcorrect |
| Stroke | 127 mmcorrect |
| Injection pressure | 300 barcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,740 mmcorrect |
|---|---|
| Width | 1,982 mmcorrect |
| Height | 2,515 mmcorrect |
| Wheelbase | 2,130 mmcorrect |
| Ground clearance | A: 210 mmcorrect |
| Unladen weight | 2,385 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 8V/8R or 12V/4Rcorrect |
| Front tyres | 7.50 R 16 ASF (A: 11.2 R 24 AS)correct |
| Rear tyres | 16.9 R 30 AScorrect |
| Top speed | 30 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 18.5 kW/t (44 kW / 2.4 t)
Power class: Universal (40–100 hp)
Stronger than 42% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the AGCO Massey Ferguson MF 4220 (A) have?
The AGCO Massey Ferguson MF 4220 (A) delivers 60 hp.
How much does the AGCO Massey Ferguson MF 4220 (A) weigh?
The unladen weight is 2,385 kg.
What engine does the AGCO Massey Ferguson MF 4220 (A) have?
3 cylinders, 2,500 cm³ displacement, Diesel.
How fast does the AGCO Massey Ferguson MF 4220 (A) go?
Top speed is 30 km/h.
What are the dimensions of the AGCO Massey Ferguson MF 4220 (A)?
3,740 mm × 1,982 mm × 2,515 mm.
When was the AGCO Massey Ferguson MF 4220 (A) built?
Production years: 1997–2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
