White 6510
Built: 1998-2001 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Built in 1998-2001, the White 6510 is a tractor from White. The four-cylinder engine produces 63 kW. Rated speed is 2,200 rpm.
Gearbox: Partial Synchro.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 3.7 to 169 kW; with 63 kW, the 6510 sits in the mid-field. Directly alongside are the American 80 with 60 kW below and the 2-88 Field Boss with 64 kW above.
Technical data
Engine
| Engine make | Cumminscorrect |
|---|---|
| Engine model | B3.9correct |
| Fuel | dieselcorrect |
| Power | 85 hp (63 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 239 cu incorrect |
| Bore | 4.02 in (102,1 mm)correct |
| Stroke | 4.72 in (119,9 mm)correct |
| Turbocharger | wastegate turbochargercorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 161 in (4089,4 mm)correct |
|---|---|
| Width | 78 omcorrect |
| Height | 103 in (2616,2 mm)correct |
| Wheelbase | 99 in (2514,6 mm)correct |
| Unladen weight | 6, 820 lbs (2WD); 8, 360 lbs (MFWD)correct |
Drivetrain and chassis
| Drive | rear-wheel driveWD/MFWDcorrect |
|---|---|
| Gearbox | Partial Synchrocorrect |
| Forward gears | 12correct |
| Reverse gears | 4correct |
Working data
| Lifting capacity | 4,100 lbs (1859,7 kg)correct |
|---|---|
| Fuel tank capacity | 37 galcorrect |
| PTO speed | 540/1000correct |
| Linkage category | Cat IIcorrect |
Origin and approval
| Plant | Beauvais, Francecorrect |
|---|
Frequently asked questions
How much power does the White 6510 have?
The White 6510 delivers 85 hp.
What engine does the White 6510 have?
4 cylinders, Diesel.
When was the White 6510 built?
Production years: 1998-2001.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 28 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
