Volvo F7/5200
Built: 1985 · Series: F7
More machines from model year 1985
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Volvo F7: heavy N3-class lorry with a six-cylinder engine, 6,700 cc displacement, 157 kW output, four wheels and a gross vehicle weight of 19,000 kg, built 1983 to 1986
The F7 was Volvo's medium-heavy lorry series, built from 1978 to 1988, sitting between the lighter Volvo models and the manufacturer's heavy long-haul series. The vehicle recorded here dates from 1983 to 1986.
Read on 3 more paragraphs
The F7 is driven by a six-cylinder engine of 6,700 cc displacement producing 157 kW. At a length of 5,870 mm and a width of 2,500 mm, the vehicle rides on four wheels and a wheelbase of 3,370 mm; kerb weight is 5,960 kg.
At a gross vehicle weight of 19,000 kg the F7 falls into EU class N3 above 12 t, for which a top speed of 90 km/h applies across the EU. Kerb weight and gross weight differ by 13,040 kg of payload margin, a substantial figure for a chassis with only four wheels, pointing to a short, manoeuvrable body for construction or distribution work rather than a long-haul body. The short length of 5,870 mm at this gross weight also means high axle loads on only two axles.
Buying an F7 of this era second-hand, it pays to check the turbocharger and injection pump of the six-cylinder engine, since both are known weak points at high mileage. The front and rear axles should be checked for wear on springs and bearings given the large payload margin, and given the early-to-mid-1980s build year, frame corrosion is also worth a look, along with the clutch, which is heavily stressed by the short wheelbase and high axle loads in construction work.
Sources: SpecCodex-Register: Kennwerte des Modells F7
Technical data
Engine
| Power | 157 kWcorrect |
|---|---|
| Displacement | 6,700 cm³correct |
Dimensions and weights
| Width | 2,490 mmcorrect |
|---|---|
| Unladen weight | 7,200 kgcorrect |
Where this model stands
Power-to-weight ratio: 21.8 kW/t (157 kW / 7.2 t)
Stronger than 19% of the trucks in the register — out of 25,242 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Volvo F7/5200 have?
The Volvo F7/5200 delivers 157 kW.
How much does the Volvo F7/5200 weigh?
The unladen weight is 7,200 kg.
What engine does the Volvo F7/5200 have?
6,700 cm³ displacement.
When was the Volvo F7/5200 built?
Production years: 1985.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 5 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
