TYM T2300T-Gen

Built: 2023-2023 · Series: Other models

Source: https://www.wirtgen-group.com/ocs/en-mn/voegele/mt-3000-3-st

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The TYM T2300T-Gen is a machine built by TYM. Production: 2023. The fuel is 7-15 ppm Ultra Low Sulfur Diesel. The rated output is 36 kW. The engine is turbocharged. The engine meets emissions stage Interim Tier 4. Fuel reaches the combustion chamber through indirect injection. Charging is by a wastegate turbocharger. It is a four-stroke diesel engine. The cylinders are arranged in line. Rated output across the TYM range ranges from 16 to 64 kW; the T2300T-Gen sits in the middle of that range with 36 kW. Its immediate neighbours are the T2000N2 below it with 30 kW and the T2300T2 above it with 41 kW. 137 TYM models across 4 series are on record. The model is listed under Non-road diesel engines. 24 verified figures from 1 source are on file.

Technical data

Engine

Engine familyPTYCL2.39A45correct
Engine familiesPTYCL2.39A45correct
Fuel7-15 ppm Ultra Low Sulfur Dieselcorrect
Rated output36 kWcorrect
Power band19<=kW<37correct
Rated speed1,800 rpmcorrect
Maximum torque186.9 N·mcorrect
Speed at max. torque1,800 rpmcorrect
Cylinders4correct
Cylinder layoutin linecorrect
Bore88 mmcorrect
Stroke94 mmcorrect
Operating cyclefour-stroke dieselcorrect
Injectionindirect injectioncorrect
Aspirationturbochargedcorrect
Turbocharger typewastegate turbochargercorrect
Emissions stageInterim Tier 4correct

Origin and approval

Built from2023correct
Built to2023correct
Model year from2023correct
Model year to2023correct
Sales regionbothcorrect

Frequently asked questions

How much power does the TYM T2300T-Gen have?

The TYM T2300T-Gen delivers 36 kW.

When was the TYM T2300T-Gen built?

Production years: 2023.

What to check before buying

  • Match the data plate against the order: frame size, mounting and rating have to agree.
  • For used units, ask about winding condition and bearing play.
  • Ask about parts availability for this series — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 24 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
