TYM T2300N2
Built: 2023-2026 · Series: Other models
More machines from model year 2023
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
TYM – other nonroad diesel engines: the collective page of tractor engines from the South Korean maker outside the named ranges, 16 to 64 kW, three- and four-cylinder, Tier 3 to Tier 4 Final
TYM Corporation, which emerged from the South Korean farm-machinery maker Tong Yang Moolsan, builds compact and utility tractors together with its own diesel engines, sold in North America under the export brand TYM. This page gathers the engines the register could not assign to a named range; the model designations in the version column, such as T1100N2, T1700N3 or T2300TC4, match TYM's own tractor series from T1100 to T3400, for which the individual engines are designed.
Read on 3 more paragraphs
The register lists here 21 versions with 16 to 64 kW rated output at 1,800 to 2,800 rpm, from three- to four-cylinders with 78 to 98 mm bore and 82 to 113 mm stroke. Maximum torque ranges from 62 to 336.7 Nm, model years from 2023 to 2026. Injection is mostly indirect (19 of 21), the emission stages split into Tier 4 (Final or Phase-in) with 16, Interim Tier 4 with 4 and Tier 3 with one version; the 19 to 37 kW power category is the most common with 9 versions.
Engines of this class drive TYM's own compact-tractor range, sold in North America under the TYM brand and through trade partners, with a focus on farmyard, municipal and small agricultural applications.
On a used purchase, operating hours and the service history of the injection pump or injectors count, on the turbocharged versions the condition of the turbocharger, the tightness of crankshaft seals and valve cover, and on the newer model years the function of the exhaust aftertreatment; since the model years only start in 2023, parts supply through TYM's authorised dealers is generally straightforward.
Sources: Kennwerte der Modelle TYM (weitere Nonroad-Dieselmotoren), TYM (Hersteller)
Technical data
Engine
| Engine code | T2300N2correct |
|---|---|
| Engine family | STYCL2.29A48correct |
| Engine families | STYCL2.29A48; TTYCL2.29A48; PTYCL2.29A48; RTYCL2.29A48correct |
| Fuel | 7-15 ppm Ultra Low Sulfur Dieselcorrect |
| Rated output | 36 kWcorrect |
| Power band | 19<=kW<37correct |
| Rated speed | 2,600 rpmcorrect |
| Maximum torque | 150 N·mcorrect |
| Speed at max. torque | 1,600 rpmcorrect |
| Cylinders | 4correct |
| Cylinder layout | in linecorrect |
| Bore | 88 mmcorrect |
| Stroke | 94 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | indirect injectioncorrect |
| Aspiration | naturally aspiratedcorrect |
| Emissions stage | Tier 4 (Final or Phase In)correct |
Origin and approval
| Version | T2300N2correct |
|---|---|
| Built from | 2023correct |
| Built to | 2026correct |
| Model year from | 2023correct |
| Model year to | 2026correct |
| Sales region | bothcorrect |
Frequently asked questions
How much power does the TYM T2300N2 have?
The TYM T2300N2 delivers 36 kW.
When was the TYM T2300N2 built?
Production years: 2023-2026.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 25 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
