Tianjin Lovol Engines 1004D-4TA65
Built: 2011 · Series: Other models
More machines from model year 2011
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Tianjin Lovol Engines – other nonroad diesel engines: the collective page of the 1004D/1006D ranges outside the named models, 60 to 115 kW, four- to six-cylinders, Tier 3
Tianjin Lovol Engines, the engine plant of the Chinese Lovol group (Foton Lovol Heavy Industry), builds diesel engines for tractors and construction machinery; the model designations 1004D for the four-cylinder range and 1006D for the six-cylinder range follow an industry-common numbering scheme in which the first digit marks the range family and the last two the cylinder count. The added TA marking indicates turbocharging, the following number (60 to 115) the power step in kW.
Read on 3 more paragraphs
The register lists here 9 versions with 60 to 115 kW rated output at 2,200 to 2,300 rpm, from four- to six-cylinders with a constant 100 mm bore and 127 mm stroke. Maximum torque ranges from 320 to 610 Nm at 1,500 to 1,600 rpm. All engines have waste-gate turbocharging and direct injection, run on low-sulphur diesel (300 to 500 ppm) and are certified to Tier 3; the 75 to under 130 kW power category forms the majority with 5 of 9 versions, and certification covers the states outside California.
Engines of this size class drive medium-size tractors, wheel loaders and excavators as well as generator sets; as an engine supplier, Lovol equips both the group's own farm machinery and outside construction-machinery makers in the mid power segment.
On a used purchase, operating hours count, the condition of the turbocharger and its waste-gate control, the injection pump or its nozzles, and the tightness of crankshaft seals and charge-air ducting; since the engines are certified only for states outside California, using them there requires checking eligibility beforehand. Spares run through the Lovol distribution network.
Sources: SpecCodex register, model data: Tianjin Lovol Engines (weitere Nonroad-Dieselmotoren)
Technical data
Engine
| Engine family | BTLEL3.994TAcorrect |
|---|---|
| Fuel | 300-500 ppm Low Sulfur Dieselcorrect |
| Rated output | 65 kWcorrect |
| Power band | 56<=kW<75correct |
| Rated speed | 2,200 rpmcorrect |
| Maximum torque | 360 N·mcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Cylinder layout | in linecorrect |
| Bore | 100 mmcorrect |
| Stroke | 127 mmcorrect |
| Operating cycle | four-stroke dieselcorrect |
| Injection | direct injectioncorrect |
| Aspiration | turbochargedcorrect |
| Turbocharger type | wastegate turbochargercorrect |
| Charge-air cooling | aircorrect |
| Emissions stage | Tier 3correct |
Origin and approval
| Sales region | USA excluding Californiacorrect |
|---|
Frequently asked questions
How much power does the Tianjin Lovol Engines 1004D-4TA65 have?
The Tianjin Lovol Engines 1004D-4TA65 delivers 65 kW.
When was the Tianjin Lovol Engines 1004D-4TA65 built?
Production years: 2011.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
