Terex TG190

Series: Terex Motor Grader

Source: https://www.terex.com/rough-terrain-cranes/en/product/rough-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Terex Motor Grader series from Terex includes the TG190. The engine delivers 187.6 hp, has 6 cylinders, with a displacement of 5,997.7 cm³. Rated speed is 2,000 rpm. The wheelbase measures 6,138.7 mm. Ground clearance is 609.6 mm. The tank holds 480.4 litres. The hydraulic tank holds 170.3 litres. Working pressure is 184 bar. The cooling system holds 42 litres. The electrical system runs on 24 V. Tyre size: 14,00 -24TG. The Terex Motor Grader series covers 4 models. Rated output within it ranges from 165.3 to 187.6 hp; the TG190 sits at the top of that range with 187.6 hp. Its immediate neighbours are the TG190TA-3 below it with 178.4 hp. 377 Terex models across 29 series are on record. The model is listed under Motor graders. 15 verified figures from 1 source are on file.

Technical data

Engine

Power187.6 hpcorrect
Rated speed2,000 rpmcorrect
Cylinders6correct
Displacement5,997.7 cm³correct
Aspirationturbochargedcorrect
Coolant capacity42 lcorrect

Dimensions and weights

Length10,268.7correct
Wheelbase6,138.7correct
Ground clearance609.6correct

Drivetrain and chassis

Gearbox typeAuto Power Shift Tansmission With torque Convertercorrect
Tyre size14.00 -24TGcorrect
System voltage24 Vcorrect

Working data

Hydraulic oil capacity170.3 lcorrect
Hydraulic pressure184correct
Fuel tank capacity480.4 lcorrect

Frequently asked questions

How much power does the Terex TG190 have?

The Terex TG190 delivers 188 hp.

What engine does the Terex TG190 have?

6 cylinders, 5,998 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
