Stehmann ZZP 18
Built: 2011-2018 · Series: Other models
More machines from model year 2011
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Stehmann – other trailers: the collective page of tippers and special versions outside the named ranges between ZZP, AZP and SDV, 3.02 to 12.54 t unladen weight, up to 39 t gross weight
This page gathers the Stehmann trailers the register could not assign to a named range – mostly tipper and push-floor versions for construction and waste-disposal firms. The type codes ZZP, ZZV, ZZW, AZP, AZV, AZW and SDV order the individual ranges of the maker's programme, with the following digits marking the size step within a range.
Read on 3 more paragraphs
The register lists here 25 versions with unladen weights from 3,020 to 12,540 kg, gross weights from 8,000 to 39,000 kg, lengths from 7,050 to 14,004 mm and widths from 2,200 to 2,600 mm.
Tipper trailers and semi-trailers of this weight class are standard equipment in earthworks, recycling and waste disposal, where bulk goods such as excavated soil, scrap or building rubble need fast loading and unloading; the span from light two-axle units to heavy three-axle units covers both municipal and industrial use, from the road site to the recycling yard.
On used units, the condition of the tipping body against wear and rust-through counts, the function and tightness of the tipping cylinders, side boards and their locks, the brake system with axles, and the frame and coupling; on push-floor versions also the condition of the push bars and the drive unit. Parts for hydraulic cylinders, axles and brakes run through independent commercial-vehicle suppliers.
Technical data
Dimensions and weights
| Length | 10,260 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 7,900 mmcorrect |
| Unladen weight | 5,280 kgcorrect |
| Gross vehicle weight | 18,000 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Stehmann ZZP 18 weigh?
The unladen weight is 5,280 kg.
What is the gross vehicle weight of the Stehmann ZZP 18?
18,000 kg.
Up to what speed is the Stehmann ZZP 18 approved?
Approved up to 100 km/h.
What are the dimensions of the Stehmann ZZP 18?
10,260 mm × 2,550 mm.
When was the Stehmann ZZP 18 built?
Production years: 2011-2018.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
