Scat Trak 1500DX

Series: Scat Trak Skid Steer Loader

Source: https://commons.wikimedia.org/wiki/File:Scat_Trak_1300D.JPEG

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Scat Trak 1500DX belongs to the Scat Trak Skid Steer Loader series. The engine delivers 60.8 hp (44.7 kW), has 4 cylinders, with a displacement of 1,999.2 cm³. Rated speed is 2,800 rpm. The wheelbase measures 1,018 mm. Ground clearance is 203.2 mm. Top speed is 11.1 km/h. The tank holds 65.9 litres. The pump delivers 117.3 l/min. The hydraulic tank holds 37.9 litres. Working pressure is 172.4 bar. The electrical system runs on 12 V. The engine fitted is the V2003-TE. Tyre size: 10,00x16,5. The Scat Trak Skid Steer Loader series covers 8 models. Rated output within it ranges from 50.2 to 87.2 hp; the 1500DX sits in the lower part of that range with 60.8 hp. Its immediate neighbours are the 1300D below it with 50.2 hp and the 1750D above it with 87.2 hp. 8 Scat Trak models are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelV2003-TEcorrect
Power60.8 hp (44.7 kW)correct
Rated speed2,800 rpmcorrect
Cylinders4correct
Displacement1,999.2 cm³correct
Aspirationturbochargedcorrect

Dimensions and weights

Wheelbase1,018correct
Ground clearance203.2correct

Drivetrain and chassis

Tyre size10.00x16.5correct
Top speed11.1 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow117.3 l/mincorrect
Hydraulic oil capacity37.9 lcorrect
Hydraulic pressure172.4correct
Fuel tank capacity65.9 lcorrect

Other data

Height1,981.2correct

Frequently asked questions

How much power does the Scat Trak 1500DX have?

The Scat Trak 1500DX delivers 60.8 hp.

What engine does the Scat Trak 1500DX have?

4 cylinders, 1,999 cm³ displacement.

How fast does the Scat Trak 1500DX go?

Top speed is 11.1 km/h.
