Renault MAXITY (3280 kg)

Built: 2007-2007 · Series: MAXITY

More machines from model year 2007

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The MAXITY from Renault is part of the MAXITY series. Production: 2007. The engine has 4 cylinders, with a displacement of 2,953 cm³. The machine is 5,500 mm long and 2,100 mm wide. The unladen weight is 3,280 kg. The wheelbase measures 2,900 mm. Top speed is 90 km/h. The gross vehicle weight is 5,200 kg. The machine runs on 6 wheels. The MAXITY series covers 8 models. Unladen weight within it ranges from 2,500 to 3,725 kg; the MAXITY sits in the upper part of that range with 3,280 kg. Its immediate neighbours are the MAXITY 150-4.5T below it with 3,172.5 kg and the Maxity above it with 3,725 kg. Gross vehicle weight within it ranges from 3,500 to 5,200 kg; here the MAXITY sits at the top of that range with 5,200 kg. 3632 Renault models across 98 series are on record.

Renault Maxity – light chassis truck up to 4.5 tonnes, 2.5 to 3.0-litre four-cylinder diesel, 107 to 110 kW, Mascott successor, shared with the Nissan Cabstar/Atleon

The Renault Maxity is a light chassis truck in the up-to-4.5-tonne weight class, which Renault introduced in 2007 as the successor to the Mascott and built in cooperation with Nissan, where the model was sold as the Cabstar or Atleon. The type designation 150-4.5T states engine output in horsepower and the 4.5-tonne weight class; the Finnish word 'alusta' in the designation 150.45/6 Alusta L3 means chassis or frame and shows that the vehicle is a bare chassis without a fixed body, while L3 denotes the wheelbase variant. The Maxity is powered by a four-cylinder diesel of between 2.5 and 3.0 litres.

Read on 3 more paragraphs

The register lists 8 versions with a four-cylinder engine of 2,488 to 2,953 cm³ and outputs of 107 to 110 kW. Unladen weight ranges from 2,500 to 3,725 kg, gross vehicle weight from 3,500 to 5,200 kg. Length runs from 5,500 to 6,750 mm and width from 1,980 to 2,200 mm.

In the light-truck segment between 3.5 and 4.5 tonnes, the Maxity competed with the Iveco Daily, the light version of the Mercedes-Benz Atego 4x2 and its own group sibling, the Nissan Cabstar. As a bare chassis, the Maxity served chiefly as a base for box bodies, flatbeds and municipal vehicles in urban distribution haulage, where its compact dimensions and simpler licence requirements compared with heavy trucks gave it an edge.

On a used example, the condition of the chassis frame behind the cab should be checked, as different loads and fixings apply depending on the body fitted. The turbocharger and injection system of the four-cylinder engine are worth checking for fault codes and durability, as is the braking system on the heavier 4.5-tonne versions. Since identical technology was also used by Nissan, spare parts are available through both dealer networks.

Sources: Kennwerte der Modelle Renault Maxity, Renault Trucks (Hersteller)

Technical data

Engine

Cylinders4correct
Displacement2,953 cm³correct

Dimensions and weights

Length5,500 mmcorrect
Width2,100 mmcorrect
Wheelbase2,900 mmcorrect
Unladen weight3,280 kgcorrect
Gross vehicle weight5,200 kgcorrect

Drivetrain and chassis

Wheels6correct
Top speed90 km/hcorrect

Frequently asked questions

How much does the Renault MAXITY weigh?

The unladen weight is 3,280 kg.

What is the gross vehicle weight of the Renault MAXITY?

5,200 kg.

What engine does the Renault MAXITY have?

4 cylinders, 2,953 cm³ displacement.

How fast does the Renault MAXITY go?

Top speed is 90 km/h.

What are the dimensions of the Renault MAXITY?

5,500 mm × 2,100 mm.

When was the Renault MAXITY built?

Production years: 2007.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
