Pel-Job EB350

The EB350 from Pel-Job is part of the Pel-Job Mini Excavator series. The engine delivers 37.5 hp (21.8 kW), has 4 cylinders, with a displacement of 1,758.3 cm³. Torque is 102.1 Nm. Rated speed is 2,800 rpm. The unladen weight is 3,582 kg. Ground clearance is 292.6 mm. The tank holds 66.2 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 90.5 l/min. The hydraulic tank holds 62.1 litres. Working pressure is 230 bar. The cooling system holds 8.3 litres. The oil fill is 7.9 litres. The electrical system runs on 12 V. The engine fitted is the S4L2. The Pel-Job Mini Excavator series covers 18 models. Rated output within it ranges from 19.3 to 42.6 hp; the EB350 sits in the upper part of that range with 37.5 hp. Its immediate neighbours are the EB30.4 below it with 27.8 hp and the EB450 above it with 42.6 hp. 21 Pel-Job models across 2 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.
