Nord HE
Series: Other models
Source: https://www.nord.com/de/home.jsp
The HE from Nord is a three-phase induction motor. The rated output is 11 kW. The motor is four-pole, which at 50 Hz gives a synchronous speed of 1,500 rpm. The housing is frame size 160 M in foot-mounted form. The protection class is IP56 and IP55. The efficiency is 90.2 per cent at full load, 91.4 per cent at 75 per cent load and 91.3 per cent at half load. Mounting arrangements to IEC 60034-7: B3, B14 and B5. The motor is built in China. The values are recorded in the Australian MEPS registration under the GEMS Determination 2012; measured to AS/NZS 1359.102.3:2000. Rated output across the Nord range ranges from 0.75 to 55 kW; the HE sits in the lower part of that range with 11 kW. Its immediate neighbours are the GBN IE3 160SP below it with 9.2 kW and the GBN IE3 160LP above it with 15 kW. 40 Nord models are on record. The model is listed under Electric motors. 21 verified figures from 1 source are on file.
Technical data
Engine
| Rated output | 11 kWcorrect |
|---|
Electrical data
| Number of poles | 4correct |
|---|---|
| Protection class | IP56, IP55correct |
| Frame size | 160 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B14, B5correct |
| Efficiency at full load | 90.2 %correct |
| Efficiency at 75 % load | 91.36 %correct |
| Efficiency at half load | 91.3 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|---|
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Nord HE have?
The Nord HE delivers 11 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
