Nooteboom ASDV 30-121
Built: 2004-2004 · Series: ASDV
More machines from model year 2004
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Nooteboom ASDV – semi low-loader range from the Dutch manufacturer: 19,350 to 36,000 kg gross weight, 5,350 to 9,140 kg unladen weight, 9.3 to 11.2 m length
This page gathers the ASDV range from the Dutch heavy-haulage specialist Nooteboom of Wijchen, which has built low-loaders and semi-trailers for construction and industrial machinery for generations. The models from ASDV 20 to ASDV 30-121 use the number to give the payload or size class in tonnes, while the suffix 12S or -12 marks the axle configuration.
Read on 4 more paragraphs
The register lists here 8 versions with unladen weights from 5,350 to 9,140 kg, gross weights from 19,350 to 36,000 kg, lengths from 9,280 to 11,200 mm and widths from 2,490 to 2,550 mm.
The ASDV range covers the middle segment of Nooteboom's programme, between light construction-machinery transporters and the marque's largest modular semi-trailers, and is used in European construction-machinery and industrial-goods transport, where the lowered loading floor gives excavators, wheel loaders and compact machinery a low loading height.
As a class O4 semi-trailer, the ASDV range needs an air brake system and driving licence category CE for towing; power transfer runs through the fifth-wheel coupling and kingpin on the dropped neck construction. The lowered frame between the axles on semi low-loaders is typically mounted on sprung axles with hydraulic steering of the rear axle group, which eases manoeuvring with long construction machines.
On a used semi-trailer, the condition of the frame and lowered loading floor, corrosion at welds and loading ramps, the braking system and axles, wear on the kingpin and landing legs, and the periodic-inspection history all count; parts run through Nooteboom itself and the usual trailer suppliers.
Sources: Kennwerte der Modelle Nooteboom ASDV
Technical data
Dimensions and weights
| Length | 10,400 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 6,200 mmcorrect |
| Unladen weight | 7,980 kgcorrect |
| Gross vehicle weight | 30,000 kgcorrect |
Drivetrain and chassis
| Wheels | 6correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Nooteboom ASDV 30-121 weigh?
The unladen weight is 7,980 kg.
What is the gross vehicle weight of the Nooteboom ASDV 30-121?
30,000 kg.
Up to what speed is the Nooteboom ASDV 30-121 approved?
Approved up to 100 km/h.
What are the dimensions of the Nooteboom ASDV 30-121?
10,400 mm × 2,550 mm.
When was the Nooteboom ASDV 30-121 built?
Production years: 2004.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 9 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
