Ningbo Kingdom Motor Electric MAE1
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Ningbo Kingdom Motor Electric – other models: the collective page of MEPS-registered three-phase motors from the Chinese works in Zhejiang outside the named ranges, frame sizes 100 to 132, 2.2 to 7.5 kW, two-pole, IP55
Ningbo Kingdom Motor Electric is a motor works in China's Zhejiang province. This page gathers the three-phase motors that the Australian energy-efficiency register (GEMS/MEPS) does not assign to a named range. The four versions carry the designations MAE1, MAE1-132S-2P, MAV1 and MCE1-132S-2P.
Read on 3 more paragraphs
The register lists here four versions with 2.2 to 7.5 kW rated output, all two-pole. Full-load efficiency ranges from 84.91 to 90.23%, and at 75% load from 84.44 to 90.3%. Frame sizes fall between 100 and 132, the protection class is IP55 throughout, and the mounting codes span B3, B14 and B34. Testing followed the Greenhouse and Energy Minimum Standards Determination 2012 with test method A; none of the four versions reaches the higher GEMS efficiency tier.
With IP55 protection and frame sizes up to 132, the range covers the smaller to medium band of classic two-pole three-phase motors used on high-speed pumps, compressors and fans.
On a used purchase, bearing condition, a tested winding insulation resistance, visible overheating traces at the terminal box and fan cover, and a legible nameplate with frame size, pole count and protection class all count. Anyone wanting variable-speed operation should check inverter compatibility beforehand. Spare parts are available through general electric-motor suppliers.
Sources: SpecCodex register, model data: Ningbo Kingdom Motor Electric (weitere Elektromotoren, MEPS-Registrierung)
Technical data
Engine
| Rated output | 2.2 kWcorrect |
|---|
Electrical data
| Number of poles | 2correct |
|---|---|
| Protection class | IP55correct |
| Frame size | 100 L (foot)correct |
| Mounting (IEC 60034-7) | B34correct |
| Efficiency at full load | 84.91 %correct |
| Efficiency at 75 % load | 84.44 %correct |
| Efficiency at half load | 81.78 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Ningbo Kingdom Motor Electric MAE1 have?
The Ningbo Kingdom Motor Electric MAE1 delivers 2.2 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 20 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
