Start › Backhoe loaders › New Holland › LB110.B

New Holland LB110.B

Series: New Holland Loader Backhoe

Source: https://www.landwirt.com/baumaschinen/radlader/new-holland/l

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The New Holland LB110.B belongs to the New Holland Loader Backhoe series. The engine delivers 82 kW, has 4 cylinders, with a displacement of 4,501.5 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,176.3 mm. Ground clearance is 371.9 mm. The tank holds 130.2 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 160.1 l/min. The hydraulic tank holds 137 litres. Working pressure is 210 bar. The cooling system holds 24.2 litres. The electrical system runs on 12 V. The engine fitted is the CNH F4GE0484G*D. The New Holland Loader Backhoe series covers 25 models. Rated output within it ranges from 48.5 to 82 kW; the LB110.B sits at the top of that range with 82 kW. Its immediate neighbours are the B110C below it with 80.5 kW. 502 New Holland models across 32 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCNH F4GE0484G*Dcorrect
Power82 kWcorrect
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,501.5 cm³correct
AspirationTurbocharged-Intercooledcorrect
Coolant capacity24.2 lcorrect

Dimensions and weights

Wheelbase2,176.3correct
Ground clearance371.9correct

Drivetrain and chassis

Gearbox typePowerShuttlecorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow160.1 l/mincorrect
Hydraulic oil capacity137 lcorrect
Hydraulic pressure210correct
Fuel tank capacity130.2 lcorrect

Frequently asked questions

How much power does the New Holland LB110.B have?

The New Holland LB110.B delivers 82 kW.

What engine does the New Holland LB110.B have?

4 cylinders, 4,502 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
