New Holland L125

Series: New Holland Skid Steer Loader

Source: https://www.landwirt.com/detail/new-holland-ts125a-plus-6338

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the L125, New Holland offers a model from the New Holland Skid Steer Loader series. The engine delivers 16.7 hp (12.3 kW), has 3 cylinders, with a displacement of 675.1 cm³. Rated speed is 3,600 rpm. The wheelbase measures 810.8 mm. Ground clearance is 172.7 mm. Top speed is 9.3 km/h. The tank holds 22.7 litres. The pump delivers 30.3 l/min. The hydraulic tank holds 34.1 litres. Working pressure is 110.3 bar. The cooling system holds 4.5 litres. The electrical system runs on 12 V. The engine fitted is the NH673. Tyre size: 23X8,50-12. The New Holland Skid Steer Loader series covers 18 models. Rated output within it ranges from 16.7 to 82.1 hp; the L125 sits at the bottom of that range with 16.7 hp. Its immediate neighbours are the L120 above it with 18.2 hp. 502 New Holland models across 32 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelNH673correct
Power16.7 hp (12.3 kW)correct
Rated speed3,600 rpmcorrect
Cylinders3correct
Displacement675.1 cm³correct
Coolant capacity4.5 lcorrect

Dimensions and weights

Wheelbase810.8correct
Ground clearance172.7correct

Drivetrain and chassis

Tyre size23X8.50-12correct
Top speed9.3 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow30.3 l/mincorrect
Hydraulic oil capacity34.1 lcorrect
Hydraulic pressure110.3correct
Fuel tank capacity22.7 lcorrect

Other data

Cab height1,761.7correct

Frequently asked questions

How much power does the New Holland L125 have?

The New Holland L125 delivers 16.7 hp.

What engine does the New Holland L125 have?

3 cylinders, 675 cm³ displacement.

How fast does the New Holland L125 go?

Top speed is 9.3 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
