Mustang 742

Series: Mustang Telescopic Forklift

Source: https://www.technikboerse.com/gebraucht/teleskoplader-354/ca

The Mustang Telescopic Forklift series from Mustang includes the 742. The engine delivers 117 hp (86.1 kW), with a displacement of 4,501.5 cm³. The machine is 2,300 mm high. The unladen weight is 10,478 kg. The wheelbase measures 3,200.4 mm. The gearbox has 4 forward gears. There are also 2 reverse gears. The pump delivers 163.2 l/min. The hydraulic tank holds 170.3 litres. Working pressure is 207 bar. Lift height is 12,800 mm. The engine fitted is the e 4045T. Tyre size: 13,00x24. The Mustang Telescopic Forklift series covers 8 models. Rated output within it ranges from 100.4 to 1,170 hp; the 742 sits at the bottom of that range with 117 hp. Its immediate neighbours are the 944 below it with 116.6 hp and the 519 above it with 158.2 hp. Unladen weight within it ranges from 6,849.2 to 15,717 kg; here the 742 sits in the middle of that range with 10,478 kg. 43 Mustang models across 9 series are on record.

Mustang telehandlers 519 to 1155 – the Gehl twins in red: the first digits as capacity in thousand pounds, the last as lift height in feet, John Deere 4045T engines of 4.5 litres, 74 to 116 kW, 6.8 to 15.7 t

Mustang's telehandlers are the red twins of the Gehl RS range: since Gehl of West Bend took over the Mustang brand in 1997, skid steers and telehandlers were sold identically in yellow and red, and after Manitou bought both in 2008 that continued until Mustang was absorbed into the Manitou brand in 2020. The type logic follows the American convention: the first digits give the capacity in thousand pounds, the last the lift height in feet – a 519 lifts 5,000 lb to 19 ft, a 642 6,000 lb to 42 ft, an 842 8,000 lb to 42 ft, a 944 9,000 lb to 44 ft, an 1155 11,000 lb to 55 ft. The engines are almost throughout John Deere 4045T, the four-cylinder turbodiesel of 4.5 litres regarded in North America as the standard engine of the class, at 2,500 to 2,600 rpm; a Deutz TD 2009 in the register belongs to a small model.

Read on 3 more paragraphs

The register lists 8 versions with 73.8 to 116.3 kW from four-cylinders of 4,502 to 4,523 cm³, service weights from 6,849 to 15,717 kg and heights from 1,930 to 2,410 mm.

The American telehandler is the machine of building construction that lifts pallets, roof trusses and masonry to storey height – Mustang and Gehl competed in it with JLG, Genie, JCB and Caterpillar; the Manitou MT range continues the programme.

On used machines, operating hours, the condition of boom, wear pads and telescope chains, leak-free cylinders, load-moment limiter, axles and tyres and parts supply, which runs through Manitou and John Deere, count – a Gehl dealer knows the Mustang.

Sources: Kennwerte der Modelle Mustang Teleskoplader, Manitou Group (Rechtsnachfolger Mustang)

Technical data

Engine

Engine model	e 4045Tcorrect
Power	117 hp (86.1 kW)correct
Displacement	4,501.5 cm³correct
Aspiration	turbochargedcorrect

Dimensions and weights

Height	2,300 mmcorrect
Wheelbase	3,200.4correct
Unladen weight	10,478 kgcorrect

Drivetrain and chassis

Gearbox type	powershift transmissioncorrect
Forward gears	4correct
Reverse gears	2correct
Tyre size	13.00x24correct

Working data

Lift height	12,800 mmcorrect
Pump flow	163.2 l/mincorrect
Hydraulic oil capacity	170.3 lcorrect
Hydraulic pressure	207correct

More machines with this engine (e 4045T, 7)

Where this model stands

Power-to-weight ratio: 8.2 kW/t (86 kW / 10.5 t)

Stronger than 71% of the telehandlers in the register — out of 661 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Mustang 742 have?

The Mustang 742 delivers 117 hp.

How much does the Mustang 742 weigh?

The unladen weight is 10,478 kg.

What engine does the Mustang 742 have?

4,502 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
