MAN 10.225 FL/365
Built: 2003 · Series: 10.225
More machines from model year 2003
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The MAN 10.225 FL/365 is a version of the L2000 with the larger engine: 162 kW from 6,870 cm³ displacement. MAN introduced the L2000 in 1993 as the successor to the G90, with a new chassis, new engines, a ZF gearbox and a cab based on a Steyr design. The entry gives the year 2003 for this variant.
The recorded dimensions are 7,450 mm long and 2,550 mm wide. The width of 2,550 mm corresponds to the dimension that is usual in Europe for truck bodies. Kerb weight is 5,130 kg and permissible gross weight 10,500 kg; the remaining payload follows from the two.
In the dataset the variant stands beside other versions of the same type number. The number after the slash tells them apart, and anyone matching vehicle papers or spare parts should always give it, since length, width and weight differ markedly between the versions.
MAN 10.225 – 10.5-tonne class truck with a 225hp engine: 6,870cc six-cylinder, LAEC-10.5T-4X4 all-wheel-drive versions, unladen weight 5.13 to 7.65 tonnes
The 10.225 continues MAN's type logic of weight class and horsepower figure: the 225 refers to about 225hp, measured here at a constant 162kW. Two versions carry the designation LAEC-10.5T-4X4, directly naming the 10.5-tonne all-wheel-drive version; the suffixes /365 and /395 distinguish the wheelbase, and LLC marks a further chassis variant. MAN was formed in 1908 from the merger of Maschinenfabrik Augsburg with the Nuremberg-based Maschinenbau-Actien-Gesellschaft; the M90 generation, to which the 10.225 belongs, supplemented the L2000 and M2000 programmes from the 1980s.
Read on 3 more paragraphs
The register lists 5 versions at a constant 162kW, a displacement of 6,870cc, unladen weights from 5,130 to 7,650kg, a uniform gross vehicle weight of 10,500kg, lengths from 6,200 to 8,120mm and widths from 2,450 to 2,560mm.
With slightly more power than the 10.223, the 10.225 suited tipper, construction and off-road duty in particular, where the all-wheel-drive versions showed their strengths; its field of use largely overlapped with the 10.223 range. Municipal operators often ran the 10.225 with crane or tipper bodies, while the all-wheel-drive versions found their way into forestry and disaster-relief vehicles.
Buying used, check the frame for rust, the condition of the clutch and gearbox, on 4X4 versions the transfer case and axle drive, the brakes, and the body and hydraulics depending on application; spare parts run through the MAN network. The tightness of the cab mounts and the condition of the tow hitch, where fitted, are also worth checking.
Sources: SpecCodex register, model data: MAN 10.225, MAN (manufacturer)
Technical data
Engine
| Power | 162 kWcorrect |
|---|---|
| Displacement | 6,870 cm³correct |
Dimensions and weights
| Length | 7,450 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Unladen weight | 5,130 kgcorrect |
| Gross vehicle weight | 10,500 kgcorrect |
Where this model stands
Power-to-weight ratio: 31.6 kW/t (162 kW / 5.1 t)
Stronger than 20% of the trucks in the register — out of 25,242 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the MAN 10.225 FL/365 have?
The MAN 10.225 FL/365 delivers 162 kW.
How much does the MAN 10.225 FL/365 weigh?
The unladen weight is 5,130 kg.
What is the gross vehicle weight of the MAN 10.225 FL/365?
10,500 kg.
What engine does the MAN 10.225 FL/365 have?
6,870 cm³ displacement.
What are the dimensions of the MAN 10.225 FL/365?
7,450 mm × 2,550 mm.
When was the MAN 10.225 FL/365 built?
Production years: 2003.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
