Madill T2250B
Series: Madill Feller Buncher
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Madill feller bunchers 1200 to 3200C – the steep-slope machines of the Canadian west coast: 1200 and 1250 as the light, 2200 to 3200 as the heavy range, T for the levelling version, Cummins, Isuzu and Detroit engines of 7.8 to 9.0 litres, 213 to 227 kW
Madill of Nanaimo on Vancouver Island is the forestry-machine builder of the Canadian west coast: since 1911 as a supplier to the timber industry, since the 1970s with its own yarders, loaders and feller bunchers for the steep slopes of British Columbia, Washington and Oregon, where Douglas firs and hemlocks of two metres in diameter stand on which the machines of the South fail. Feller bunchers cut the tree with a head on the boom and lay it down in bunches; the type logic: 1200 and 1250 are the lighter range, 2200, 2250 and 3200 the heavy one, B and C the generations, T marks the levelling version in which the upper structure is set horizontal on the slope. The engines come from Cummins (QSL of 8.9 litres), Isuzu (6HK1X of 7.8 litres) and Detroit Diesel (Series 50 of 8.5 litres). Madill went bankrupt in 2008; Nicholson Manufacturing of Sidney near Victoria took over the brand and carries parts and service.
Read on 3 more paragraphs
The register lists 9 versions with 212.5 to 227.4 kW from engines of 7,800 to 9,001 cm³ at 2,000 to 2,200 rpm and widths from 3,149 to 3,453 mm.
Madill machines are unknown in Europe and a byword for ruggedness in North America: the 3200C is regarded as one of the heaviest feller bunchers of its time, built for trees for which Tigercat and John Deere offer no heads.
On used machines, operating hours, the condition of undercarriage, slew ring and levelling, boom and felling head, hydraulic pumps and coolers and parts supply, which runs through Cummins, Isuzu and Detroit for the engines and Nicholson for the machine, are what count.
Sources: Kennwerte der Modelle Madill Fällbündler, Nicholson Manufacturing (Rechtsnachfolger Madill, Sidney BC)
Technical data
Engine
| Engine model | QSLcorrect |
|---|---|
| Power | 309.2 hp (227.4 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Displacement | 9,001.4 cm³correct |
| Engine oil capacity | 242.3 lcorrect |
Dimensions and weights
| Width | 3,200.4correct |
|---|---|
| Ground clearance | 61.5correct |
Drivetrain and chassis
| Forward gears | 2correct |
|---|---|
| Tyre size | Tracks- 11'4" wide, 15'9" Longcorrect |
| Top speed | 4.5 km/hcorrect |
Working data
| Fuel tank capacity | 946.4 lcorrect |
|---|
Other data
| Cab height | 3,733.8correct |
|---|---|
| System voltage | 24 Vcorrect |
More machines with this engine (CUMMINS QSL, 10)
Frequently asked questions
How much power does the Madill T2250B have?
The Madill T2250B delivers 309 hp.
What engine does the Madill T2250B have?
9,001 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
