Link-Belt L120

Series: Link-Belt Wheel Loader

Source: https://commons.wikimedia.org/wiki/File:Link-Belt_LS-98.jpg

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The L120 from Link-Belt is part of the Link-Belt Wheel Loader series. The engine delivers 111.5 hp (79 kW), has 4 cylinders, with a displacement of 3,916.5 cm³. Torque is 413.5 Nm. Rated speed is 2,200 rpm. The unladen weight is 9,301.8 kg. The wheelbase measures 2,743.2 mm. Ground clearance is 408.4 mm. The tank holds 130.2 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,500 rpm. The pump delivers 121.1 l/min. The hydraulic tank holds 120.4 litres. The electrical system runs on 24 V. The engine fitted is the 4BTA3,9. Tyre size: 17,5 R25. The Link-Belt Wheel Loader series covers 3 models. Rated output within it ranges from 111.5 to 175.4 hp; the L120 sits at the bottom of that range with 111.5 hp. Its immediate neighbours are the L125 above it with 136.9 hp. 157 Link-Belt models across 10 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model	4BTA3.9correct
Power	111.5 hp (79 kW)correct
Rated speed	2,200 rpmcorrect
Torque	413.5correct
Speed at max. torque	1,500 rpmcorrect
Cylinders	4correct
Displacement	3,916.5 cm³correct
Aspiration	Turbocharged and Intercooledcorrect

Dimensions and weights

Wheelbase	2,743.2correct
Ground clearance	408.4correct
Unladen weight	9,301.8 kgcorrect

Drivetrain and chassis

Gearbox type	Power Shiftcorrect
Forward gears	4correct
Reverse gears	3correct
Tyre size	17.5 R25correct
System voltage	24 Vcorrect

Working data

Pump flow	121.1 l/mincorrect
Hydraulic oil capacity	120.4 lcorrect
Fuel tank capacity	130.2 lcorrect

Other data

Height	3,075.4correct

Where this model stands

Power-to-weight ratio: 8.5 kW/t (79 kW / 9.3 t)

Stronger than 39% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Link-Belt L120 have?

The Link-Belt L120 delivers 112 hp.

How much does the Link-Belt L120 weigh?

The unladen weight is 9,302 kg.

What engine does the Link-Belt L120 have?

4 cylinders, 3,916 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
