Link-Belt E30
Series: Link-Belt Articulated Dump Truck
The Link-Belt Articulated Dump Truck series from Link-Belt includes the E30. The engine delivers 273.7 hp (201.3 kW), has 6 cylinders, with a displacement of 10,831.8 cm³. Torque is 1,233.8 Nm. Rated speed is 2,100 rpm. The wheelbase measures 5,459 mm. Ground clearance is 484.6 mm. Top speed is 48.3 km/h. The tank holds 325.2 litres. The gearbox has 6 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,500 rpm. The hydraulic tank holds 200.2 litres. The cooling system holds 43.2 litres. The oil fill is 34.1 litres. The electrical system runs on 24 V. The engine fitted is the M11-C270. Tyre size: 23,5 R25. The Link-Belt Articulated Dump Truck series covers 5 models. Rated output within it ranges from 138.9 to 304.2 hp; the E30 sits in the upper part of that range with 273.7 hp. Its immediate neighbours are the D25 below it with 258.5 hp and the D300 above it with 304.2 hp. 157 Link-Belt models across 10 series are on record. The model is listed under Mining equipment. 23 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | M11-C270correct |
|---|---|
| Power | 273.7 hp (201.3 kW)correct |
| Rated speed | 2,100 rpmcorrect |
| Torque | 1,233.8correct |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 10,831.8 cm³correct |
| Aspiration | Turbocharged and Aftercooledcorrect |
| Coolant capacity | 43.2 lcorrect |
| Engine oil capacity | 34.1 lcorrect |
Dimensions and weights
| Length | 9,759.7correct |
|---|---|
| Width | 2,862.1correct |
| Wheelbase | 5,459correct |
| Ground clearance | 484.6correct |
Drivetrain and chassis
| Gearbox type | Power Shiftcorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 3correct |
| Tyre size | 23.5 R25correct |
| Top speed | 48.3 km/hcorrect |
| System voltage | 24 Vcorrect |
Working data
| Hydraulic oil capacity | 200.2 lcorrect |
|---|---|
| Fuel tank capacity | 325.2 lcorrect |
Frequently asked questions
How much power does the Link-Belt E30 have?
The Link-Belt E30 delivers 274 hp.
What engine does the Link-Belt E30 have?
6 cylinders, 10,832 cm³ displacement.
How fast does the Link-Belt E30 go?
Top speed is 48.3 km/h.
What are the dimensions of the Link-Belt E30?
9,760 mm × 2,862 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
