Link-Belt ATC3200
Series: Link-Belt All Terrain Crane
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Link-Belt all-terrain cranes ATC-3130 to ATC-3275 – the all-terrain cranes from Lexington, Kentucky: ATC for All Terrain Crane, the number as capacity in US tons, 822 and LS-238H as relatives, Cummins and Mercedes engines, 172 to 388 kW, 18 to 62 t
Link-Belt of Lexington, Kentucky, is the American crane builder that has belonged to Sumitomo Heavy Industries since 1986 and, alongside lattice-boom crawler cranes, telescopic crawler cranes and truck cranes, also builds all-terrain cranes – the genre with all-wheel drive and all-wheel steering that travels at 80 km/h on the road and works off-road, in Europe the domain of Liebherr, Tadano and Grove. The type logic: ATC stands for All Terrain Crane, the number gives the capacity in US tons – ATC-3130 130 t, ATC-3200 200 t, ATC-3210 210 t, ATC-3250 250 t, ATC-3275 275 t, all with the 3 as range identifier – the ATC-822 is an older type, the LS-238H a lattice-boom crawler crane the register carries here. The engines come from Cummins (QSM11, QSX15) and Mercedes-Benz (OM 470 and OM 502), six- and eight-cylinders, whose register span up to 45 litres contains one entry with carrier and superstructure engines combined.
Read on 3 more paragraphs
The register lists 7 versions with 171.5 to 387.8 kW, torque from 660 to 2,508 Nm at 1,800 to 2,500 rpm and service weights from 17,791 to 61,842 kg.
In the North American all-terrain market Link-Belt is the only domestic supplier beside Grove; the ATC range with carriers from German suppliers is common in the USA and Canada, not represented in Europe.
On used cranes, operating hours and inspection history, the condition of telescopic boom, slew ring and outriggers, axles, suspension and tyres, load-moment limiter and parts supply through Link-Belt and the engine makers count.
Sources: Kennwerte der Modelle Link-Belt All-Terrain-Krane, Link-Belt Cranes (Hersteller, Lexington, Kentucky)
Technical data
Engine
| Power | 530.3 hpcorrect |
|---|---|
| Rated speed | 1,800 rpmcorrect |
| Torque | 749.8correct |
| Speed at max. torque | 1,300 rpmcorrect |
| Displacement | 15,929.9 cm³correct |
Dimensions and weights
| Ground clearance | 332.2correct |
|---|---|
| Unladen weight | 58,052.1 kgcorrect |
Drivetrain and chassis
| Gearbox type | automated manual gearbox transmissioncorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 2correct |
| Tyre size | 20.5R25correct |
Other data
| System voltage | 24 Vcorrect |
|---|
Where this model stands
Power-to-weight ratio: 6.7 kW/t (390 kW / 58.1 t)
Stronger than 90% of the mobile & rough terrain cranes in the register — out of 575 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Link-Belt ATC3200 have?
The Link-Belt ATC3200 delivers 530 hp.
How much does the Link-Belt ATC3200 weigh?
The unladen weight is 58,052 kg.
What engine does the Link-Belt ATC3200 have?
15,930 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
