Liebherr A314

Series: Liebherr Mobile Excavator

Source: https://www.liebherr.com/en-gb/earthmoving/products/excavato

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Liebherr A314 belongs to the Liebherr Mobile Excavator series. The engine delivers 81.3 kW, has 4 cylinders, with a displacement of 4,801.4 cm³. Rated speed is 1,800 rpm. The unladen weight is 15,250 kg. The wheelbase measures 2,542 mm. Ground clearance is 350.5 mm. The tank holds 290.3 litres. The gearbox has 2 forward gears. There are also 2 reverse gears. The pump delivers 230.2 l/min. The hydraulic tank holds 350.2 litres. Working pressure is 350 bar. The engine fitted is the BF4M1013EC. The Liebherr Mobile Excavator series covers 18 models. Rated output within it ranges from 64.1 to 225.2 kW; the A314 sits at the bottom of that range with 81.3 kW. Its immediate neighbours are the A312 below it with 76.1 kW and the A316 above it with 87.2 kW. 480 Liebherr models across 20 series are on record. The model is listed under Excavators & compaction. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBF4M1013ECcorrect
Power81.3 kWcorrect
Rated speed1,800 rpmcorrect
Cylinders4correct
Displacement4,801.4 cm³correct
AspirationDirect Injection Turbo-chargedcorrect

Dimensions and weights

Wheelbase2,542correct
Ground clearance350.5correct
Unladen weight15,250 kgcorrect

Drivetrain and chassis

Gearbox typeOversized two speed power shift transmission and integrated protection with addicorrect
Forward gears2correct
Reverse gears2correct

Working data

Pump flow230.2 l/mincorrect
Hydraulic oil capacity350.2 lcorrect
Hydraulic pressure350 barcorrect
Fuel tank capacity290.3 lcorrect

Other data

Height3,102.9correct

Where this model stands

Power-to-weight ratio: 5.3 kW/t (81 kW / 15.2 t)

Stronger than 31% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Liebherr A314 have?

The Liebherr A314 delivers 81.3 kW.

How much does the Liebherr A314 weigh?

The unladen weight is 15,250 kg.

What engine does the Liebherr A314 have?

4 cylinders, 4,801 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
