Landini Trekker 75 F 4WD
Series: Trekker
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Landini Trekker 75 F belongs to the Landini 4WD Tractor series. Under the bonnet works a four-cylinder engine displacing 4.4 litres, producing 69 hp (50.9 kW). With a rated speed of 2,200 rpm, it is built for pulling power, not for revving.
Empty, it weighs 3,792 kg.
Within the range, rated power spans from 36 to 217 hp; with 69.1 hp, the Trekker 75 F sits in the lower third. Directly alongside are the Rex 70 F with 67.8 hp below and the Alpine 65 GT with 70 hp above.
Landini Trekker – the crawler tractors from Fabbrico: Trekker 75 to 105, F for orchard, M for standard track, Perkins four-cylinders, Italian tracked tractors for slopes and vineyards, 51 to 74 kW
The Trekker is Landini's crawler tractor – a layout that never died out in Italy because the slopes of Tuscany, the vineyards of Sicily and the olive groves of Apulia demand traction and soil protection that wheeled tractors cannot offer. Landini of Fabbrico, since 1994 the core of the Argo group, has built crawlers since the 1930s, and the Trekker range of the 2000s and 2010s is the modern form: hydraulic steering clutches, cab or roll bar, PTO and rear linkage as on a wheeled tractor. The type logic: the number roughly gives the output in hp – Trekker 75, 85, 95 and 105 – F marks the orchard version (Frutteto) with narrow track, M the standard version with wider track for field work. The engines are Perkins four-cylinders of 4.4 litres in naturally aspirated and turbo form.
Read on 3 more paragraphs
The register lists 11 versions with 50.9 to 73.5 kW from the Perkins 1104C-44 of 4,400 cm³ at 2,200 rpm, PTO outputs of 63 to 91 hp, operating weights from 3,792 to 4,680 kg and 3,500 mm length.
At the same output a crawler weighs more than a wheeled tractor and spreads the weight over the track area – 4.7 t on two undercarriages means low ground pressure and traction on the slope where a wheeled tractor slips or tips; Landini shares this market with New Holland and Fiat heirs such as Same.
On used machines, undercarriage and tracks (wear of pins, bushings and rollers is the big cost item), steering clutches and brakes, the Perkins engine and hydraulics count; parts run through Argo dealers and Perkins.
Sources: Kennwerte der Modelle Landini Trekker, Landini (Argo Tractors, Hersteller)
Technical data
Engine
| Engine model | 1104C-44correct |
|---|---|
| Power | 69.1 hp (50.9 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,399.9 cm³correct |
Dimensions and weights
| Length | 3,500 mmcorrect |
|---|---|
| Ground clearance | 320correct |
| Unladen weight | 3,792 kgcorrect |
Drivetrain and chassis
| Gearbox type | Basiccorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 8correct |
Working data
| Pump flow | 64.4 l/mincorrect |
|---|---|
| Hydraulic pressure | 180correct |
| Fuel tank capacity | 80.6 lcorrect |
Other data
| Cab height | 1,170.4correct |
|---|---|
| PTO output | 63 hpcorrect |
More machines with this engine (Perkins 1104C-44, 74)
Where this model stands
Power-to-weight ratio: 13.4 kW/t (51 kW / 3.8 t)
Power class: Universal (40–100 hp)
Stronger than 47% of the tractors in the register — out of 15,659 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Landini Trekker 75 F have?
The Landini Trekker 75 F delivers 69.1 hp.
How much does the Landini Trekker 75 F weigh?
The unladen weight is 3,792 kg.
What engine does the Landini Trekker 75 F have?
4 cylinders, 4,400 cm³ displacement.
What is the PTO output of the Landini Trekker 75 F?
PTO output is 63 hp.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Trekker 105
Trekker 105 F
Trekker 105 M
Trekker 75 M
Trekker 85
Trekker 85 F
Trekker 85 M
Trekker 95
Trekker 95 F
Trekker 95 M
