Krause 7300-34N – specifications
Series: Other models
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Krause 7300-34N is a trailed tandem disc harrow used for seedbed preparation and for working stubble after harvest. The 34 in the type name refers to the working width in feet, while the N stands for the narrow disc spacing of 198.1 mm. The notched blades measure 558.8 mm in diameter and chop crop residue, and the close spacing encourages a fine, crumbly soil structure.
The wide implement rides on 11L x 15 inch tires with 8 plies, fitted on both the main frame and the wings. That lets the outer sections fold for road transport without concentrating the load on single wheels. Working depth is set with one central hydraulic stop, which Krause describes as a single-location remote stop, so the operator preselects depth from the tractor seat at a single point.
Rigid 3.5 inch scrapers keep the blade faces clear. Minimum weight is 5,602.8 kg, a mass that helps the discs bite into firmer ground.
Krause – other models: the collective page of disc-harrow ranges 2232 to 7300 from Hutchinson, Kansas, today part of Kuhn Krause
This page gathers Krause equipment the register could not assign to a single named range – from the compact disc harrows of the 2232 and 2234 series through the 2483 to 2495 ranges to the large 4995 and 7300 series. Krause has made disc harrows and other tillage equipment in Hutchinson, Kansas, for decades; since the takeover by the French Kuhn group in 2005, the plant has traded as Kuhn Krause.
Read on 3 more paragraphs
The register lists here 101 versions from the 2232, 2234, 2235, 2236, 2238, 2483, 2486, 2490, 2492 and 2495 ranges as well as the larger 4995 and 7300 series, the latter each in several working-width variants from 18 to 38, counted in feet.
Disc harrows such as Krause's serve shallow to medium-depth tillage after harvest or before sowing, chopping stubble and crop residue and mixing it into the topsoil; Krause's broad model range covers everything from the small mounted implement to the large trailed disc harrow for operations with large acreage.
When buying a used disc harrow, wear on the discs and bearings, the condition of the frame welds and, on wide folding versions, the tightness of the hydraulic cylinders for the fold function rank among the key checkpoints; spare parts run through the Kuhn Krause network, though older model years sometimes call for sourcing components from independent farm-equipment parts suppliers.
Sources: SpecCodex register, model data: Krause (weitere Modelle), Kuhn Krause (manufacturer)
Technical data
Other data
| Boom tyres | 11L x 15\" 8-plycorrect |
|---|---|
| Depth control | Single-location remote stopcorrect |
| Disc diameter | 558.8 mmcorrect |
| Disc spacing | 198.1 mmcorrect |
| Frame tyres | 11L x 15\" 8-plycorrect |
| Scrapers | 3.5\" rigidcorrect |
| Weight (min.) | 5,602.8 kgcorrect |
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
