Komatsu WB150-2N

Series: Komatsu Loader Backhoe

Source: https://www.komatsu.eu/de/alte-modelle/radlader/wa150pz-5

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Komatsu WB150-2N belongs to the Komatsu Loader Backhoe series. The engine delivers 101.4 hp (70.1 kW), has 4 cylinders, with a displacement of 4,401.6 cm³. The engine comes from Komatsu. Rated speed is 2,200 rpm. The wheelbase measures 2,176.3 mm. Ground clearance is 320 mm. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The pump delivers 165 l/min. The hydraulic tank holds 92.4 litres. Working pressure is 220.6 bar. The cooling system holds 14 litres. The electrical system runs on 12 V. The engine fitted is the S4D106-2SFA. The Komatsu Loader Backhoe series covers 16 models. Rated output within it ranges from 26.6 to 114.6 hp; the WB150-2N sits at the top of that range with 101.4 hp. Its immediate neighbours are the WB93R-5 below it with 100.7 hp and the WB97R-2 above it with 114.6 hp. 1159 Komatsu models across 39 series are on record. The model is listed under Wheel loaders. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine makeKomatsucorrect
Engine modelS4D106-2SFAcorrect
Power101.4 hp (70.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,400 rpmcorrect
Cylinders4correct
Displacement4,401.6 cm³correct
Aspirationturbochargedcorrect
Coolant capacity14 lcorrect

Dimensions and weights

Wheelbase2,176.3correct
Ground clearance320correct

Drivetrain and chassis

Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow165 l/mincorrect
Hydraulic oil capacity92.4 lcorrect
Hydraulic pressure220.6correct

Frequently asked questions

How much power does the Komatsu WB150-2N have?

The Komatsu WB150-2N delivers 101 hp.

What engine does the Komatsu WB150-2N have?

4 cylinders, 4,402 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
