Kobelco ED150

Series: Kobelco Hydraulic Excavator

Source: https://www.kobelco.com.au/blogs/kobelco-launches-unique-new

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the ED150, Kobelco offers a model from the Kobelco Hydraulic Excavator series. The engine delivers 95.3 hp (70.1 kW), has 4 cylinders, with a displacement of 4,326.2 cm³. Torque is 317.9 Nm. Rated speed is 2,200 rpm. The unladen weight is 16,202.3 kg. Ground clearance is 527.3 mm. The tank holds 168.1 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 312.7 l/min. The hydraulic tank holds 140.1 litres. Working pressure is 343.4 bar. The cooling system holds 18.2 litres. The oil fill is 13.2 litres. The engine fitted is the A-4BG1T. The Kobelco Hydraulic Excavator series covers 52 models. Rated output within it ranges from 94.1 to 374.1 hp; the ED150 sits at the bottom of that range with 95.3 hp. Its immediate neighbours are the SK135SR-2 below it with 94.1 hp and the SK140SRD-5 CAR DEMO above it with 96.9 hp. 98 Kobelco models across 6 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelA-4BG1Tcorrect
Power95.3 hp (70.1 kW)correct
Rated speed2,200 rpmcorrect
Torque317.9correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement4,326.2 cm³correct
AspirationTurbocharged dieselcorrect
Coolant capacity18.2 lcorrect
Engine oil capacity13.2 lcorrect

Dimensions and weights

Ground clearance527.3correct
Unladen weight16,202.3 kgcorrect

Working data

Pump flow312.7 l/mincorrect
Hydraulic oil capacity140.1 lcorrect
Hydraulic pressure343.4 barcorrect
Fuel tank capacity168.1 lcorrect

Other data

Cab height2,901.7correct

Where this model stands

Power-to-weight ratio: 4.3 kW/t (70 kW / 16.2 t)

Stronger than 25% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kobelco ED150 have?

The Kobelco ED150 delivers 95.3 hp.

How much does the Kobelco ED150 weigh?

The unladen weight is 16,202 kg.

What engine does the Kobelco ED150 have?

4 cylinders, 4,326 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
