Kawasaki 70TMV-2

Series: Kawasaki Integrated Tool Carrier

Source: https://www.kawasaki.eu/content/europe/master/en/Motorcycles

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 70TMV-2 from Kawasaki is part of the Kawasaki Integrated Tool Carrier series. The engine delivers 195.7 hp (129.8 kW), has 6 cylinders, with a displacement of 6,702.3 cm³. Torque is 890.8 Nm. Rated speed is 2,200 rpm. The unladen weight is 16,132.5 kg. The wheelbase measures 3,051 mm. Ground clearance is 445 mm. The tank holds 270.3 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,400 rpm. The hydraulic tank holds 170.3 litres. The cooling system holds 30.3 litres. The oil fill is 24.2 litres. The electrical system runs on 12 V. The engine fitted is the QSB6,7. Tyre size: 23,5x25-16PR (L-3). The Kawasaki Integrated Tool Carrier series covers 4 models. Rated output within it ranges from 99.9 to 129.8 kW; the 70TMV-2 sits at the top of that range with 129.8 kW. Its immediate neighbours are the 65TMV below it with 99.9 kW. 58 Kawasaki models across 2 series are on record. The model is listed under Telehandlers. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model	QSB6.7correct
Power	195.7 hp (129.8 kW)correct
Rated speed	2,200 rpmcorrect
Torque	890.8correct
Speed at max. torque	1,400 rpmcorrect
Cylinders	6correct
Displacement	6,702.3 cm³correct
Aspiration	turbo chargedcorrect
Coolant capacity	30.3 lcorrect
Engine oil capacity	24.2 lcorrect

Dimensions and weights

Wheelbase	3,051correct
Ground clearance	445correct
Unladen weight	16,132.5 kgcorrect

Drivetrain and chassis

Gearbox type	full power shiftcorrect
Forward gears	4correct
Reverse gears	4correct
Tyre size	23.5x25-16PR (L-3)correct
Turning radius	6,190 mmcorrect
System voltage	12 Vcorrect

Working data

Lift height	4,040 mmcorrect
Hydraulic oil capacity	170.3 lcorrect
Fuel tank capacity	270.3 lcorrect

Other data

Cab height	3,395.5correct

More machines with this engine (Cummins QSB6.7, 68)

Where this model stands

Power-to-weight ratio: 8 kW/t (130 kW / 16.1 t)

Stronger than 96% of the telehandlers in the register — out of 661 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 70TMV-2 have?

The Kawasaki 70TMV-2 delivers 196 hp.

How much does the Kawasaki 70TMV-2 weigh?

The unladen weight is 16,132 kg.

What engine does the Kawasaki 70TMV-2 have?

6 cylinders, 6,702 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
