Kawasaki 65TMV

Series: Kawasaki Integrated Tool Carrier

Source: https://www.kawasaki.eu/en/Motorcycles/EV_HEV/Ninja_7_Hybrid

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Kawasaki 65TMV is a model in the Kawasaki Integrated Tool Carrier series. The engine delivers 99.9 kW, has 6 cylinders, with a displacement of 5,883 cm³. Torque is 543.7 Nm. Rated speed is 2,200 rpm. The unladen weight is 11,980 kg. The wheelbase measures 2,901.7 mm. Ground clearance is 445 mm. The tank holds 222.2 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,500 rpm. The pump delivers 104.9 l/min. The hydraulic tank holds 100.3 litres. The cooling system holds 43.2 litres. The oil fill is 16.3 litres. The electrical system runs on 24 V. The engine fitted is the 6BTAA5,9. Tyre size: 20,5x25-12PR (L-2). The Kawasaki Integrated Tool Carrier series covers 4 models. Rated output within it ranges from 99.9 to 129.8 kW; the 65TMV sits at the bottom of that range with 99.9 kW. Its immediate neighbours are the 70TMV-2 above it with 129.8 kW. 58 Kawasaki models across 2 series are on record. The model is listed under Telehandlers. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model	6BTAA5.9correct
Power	99.9 kWcorrect
Rated speed	2,200 rpmcorrect
Torque	543.7correct
Speed at max. torque	1,500 rpmcorrect
Cylinders	6correct
Displacement	5,883 cm³correct
Aspiration	turbocharged 7 intercoolercorrect
Coolant capacity	43.2 lcorrect
Engine oil capacity	16.3 lcorrect

Dimensions and weights

Wheelbase	2,901.7correct
Ground clearance	445correct
Unladen weight	11,980 kgcorrect

Drivetrain and chassis

Gearbox type	full power shiftcorrect
Forward gears	4correct
Reverse gears	4correct
Tyre size	20.5x25-12PR (L-2)correct
System voltage	24 Vcorrect

Working data

Pump flow	104.9 l/mincorrect
Hydraulic oil capacity	100.3 lcorrect
Fuel tank capacity	222.2 lcorrect

Other data

Height	3,270.5correct

Where this model stands

Power-to-weight ratio: 8.3 kW/t (100 kW / 12 t)

Stronger than 82% of the telehandlers in the register — out of 658 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 65TMV have?

The Kawasaki 65TMV delivers 99.9 kW.

How much does the Kawasaki 65TMV weigh?

The unladen weight is 11,980 kg.

What engine does the Kawasaki 65TMV have?

6 cylinders, 5,883 cm³ displacement.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
