John Deere 650
Built: 1981-1989 · Series: Other models
The John Deere 650 rolled off the line in 1981-1989 as a tractor. The two-cylinder engine produces 13 kW.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 10 to 420 kW; with 13 kW, the 650 sits at the bottom end. Directly alongside are the STX38 with 10 kW below and the 670 with 13.7 kW above.
Technical data
Engine
| Engine make | Yanmarcorrect |
|---|---|
| Engine model | 2T80correct |
| Fuel | dieselcorrect |
| Power | 18 hp (13 kW)correct |
| Cylinders | 2correct |
| Displacement | 52.1 cu incorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 102.5 in (2603,5 mm)correct |
|---|---|
| Width | 41 in (1041,4 mm)correct |
| Height | 77.4 in (1 966 mm)correct |
| Wheelbase | 56 in (1422,4 mm)correct |
| Unladen weight | 1,530 lbs (694 kg)correct |
Drivetrain and chassis
| Drive | rear-wheel drive WDMFWDcorrect |
|---|
Working data
| Fuel tank capacity | 6.2 galcorrect |
|---|---|
| Linkage category | Cat Icorrect |
Origin and approval
| Plant | Japancorrect |
|---|
Frequently asked questions
How much power does the John Deere 650 have?
The John Deere 650 delivers 18 hp.
What engine does the John Deere 650 have?
2 cylinders, Diesel.
When was the John Deere 650 built?
Production years: 1981-1989.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
