John Deere 5093 E
Built: 2008-2011 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Built in 2008-2011, the John Deere 5093 E is a tractor from John Deere. It is powered by a four-cylinder engine producing 69 kW. Rated power is reached at 2,400 rpm.
Drive type: MFWD.
It runs on diesel; the engine is water-cooled. Within the range, rated power spans from 10 to 420 kW; with 69 kW, the 5093 E sits in the mid-field. Directly alongside are the 3050 4WD with 68 kW below and the 5090M with 69.2 kW above.
Technical data
Engine
| Engine make | John Deerecorrect |
|---|---|
| Engine model | PowerTech 4045correct |
| Fuel | dieselcorrect |
| Power | 93 hp (69 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 276 cu incorrect |
| Bore | 4.19 in (106,4 mm)correct |
| Stroke | 5 in (127 mm)correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 85.8 in (2179,3 mm)correct |
|---|---|
| Unladen weight | 7,385 lbs (3349,8 kg)correct |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|
Working data
| Fuel tank capacity | 33.5 galcorrect |
|---|---|
| PTO speed | 540/540Ecorrect |
| Linkage category | Cat I/IIcorrect |
Origin and approval
| Plant | Augusta, Georgia, USAcorrect |
|---|
Frequently asked questions
How much power does the John Deere 5093 E have?
The John Deere 5093 E delivers 93 hp.
What engine does the John Deere 5093 E have?
4 cylinders, Diesel.
When was the John Deere 5093 E built?
Production years: 2008-2011.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
