John Deere 2305
Built: 2006-2011 · Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The John Deere 2305 is a tractor built in 2006-2011. The three-cylinder engine, displacing 1.1 litres, produces 24 hp (18 kW). Rated speed is 3,000 rpm.
Power is transmitted through a hydrostatic gearbox, drive type: MFWD. Wheelbase is 1.45 m.
It runs on diesel; the engine is water-cooled. This model followed the John Deere 2210, before the John Deere 1026 R took over. Within the range, rated power spans from 24.3 to 507 hp; with 24.3 hp, the 2305 sits at the bottom end. The next one up is the 3720 with 44.6 hp.
Technical data
Engine
| Engine make | Yanmarcorrect |
|---|---|
| Engine model | 3TNV76correct |
| Fuel | dieselcorrect |
| Power | 24.3 hp (18 kW)correct |
| Rated speed | 3,000 rpmcorrect |
| Torque | 56.5correct |
| Speed at max. torque | 3,000 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,116 cm³ (68 ci)correct |
| Aspiration | naturalcorrect |
| Cooling | water-cooledcorrect |
| Coolant capacity | 3.4 lcorrect |
| Engine oil capacity | 3.4 lcorrect |
Dimensions and weights
| Length | 102.6 in (2 606 mm)correct |
|---|---|
| Width | 44.9 in (1140,5 mm)correct |
| Height | 77.5 in (1968,5 mm)correct |
| Wheelbase | 1,450.8 mm (57.1 in)correct |
| Unladen weight | 1,450 lbs (657,7 kg)correct |
Drivetrain and chassis
| Drive | selectable four-wheel drivecorrect |
|---|---|
| Gearbox | hydrostatic transmissioncorrect |
| Gearbox type | hydrostatic transmission- 2 rangecorrect |
| Forward gears | infinitecorrect |
| Reverse gears | infinitecorrect |
| Turning radius | 2,260 mmcorrect |
| System voltage | 12 Vcorrect |
Working data
| Lifting capacity | 309 kgcorrect |
|---|---|
| Lifting capacity | 1,433 lbs (650 kg)correct |
| Pump flow | 20.1 l/mincorrect |
| Fuel tank capacity | 21.2 l (5.5 gal)correct |
| PTO output | 18 hpcorrect |
| PTO speed | 540correct |
| Linkage category | Cat Icorrect |
Origin and approval
| Plant | Japancorrect |
|---|---|
| Predecessor | John Deere 2210correct |
| Successor | John Deere 1026 Rcorrect |
Frequently asked questions
How much power does the John Deere 2305 have?
The John Deere 2305 delivers 24.3 hp.
What engine does the John Deere 2305 have?
3 cylinders, 1,116 cm³ displacement, Diesel.
What is the PTO output of the John Deere 2305?
PTO output is 18 hp. PTO speeds: 540 rpm.
How much does the rear linkage of the John Deere 2305 lift?
The rear linkage lifts 309 kg.
When was the John Deere 2305 built?
Production years: 2006-2011.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
