John Deere JD24

Series: John Deere Skid Steer Loader

Source: https://www.tractordata.com/farm-tractors/000/0/9/96-john-de

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere JD24 belongs to the John Deere Skid Steer Loader series. The engine delivers 27.6 kW, with a displacement of 2,523.6 cm³. The wheelbase measures 887 mm. Ground clearance is 65.5 mm. Top speed is 11.3 km/h. The tank holds 94.6 litres. The pump delivers 68.1 l/min. The hydraulic tank holds 75.7 litres. Working pressure is 120.7 bar. The electrical system runs on 12 V. The engine fitted is the Wisconsin VG4D. Tyre size: 10,00-16,5.6-ply rating. R3. The John Deere Skid Steer Loader series covers 29 models. Rated output within it ranges from 12.7 to 63.4 kW; the JD24 sits in the lower part of that range with 27.6 kW. Its immediate neighbours are the 4475 below it with 23.1 kW and the 125 above it with 29.8 kW. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 13 verified figures from 1 source are on file.

Technical data

Engine

Engine modelWisconsin VG4Dcorrect
Power27.6 kWcorrect
Displacement2,523.6 cm³correct
Aspiration4-cylinder, 4-stroke cyclecorrect

Dimensions and weights

Wheelbase887correct
Ground clearance65.5correct

Drivetrain and chassis

Tyre size10.00-16.5, 6-ply rating, R3correct
Top speed11.3 km/hcorrect
System voltage12 Vcorrect

Working data

Pump flow68.1 l/mincorrect
Hydraulic oil capacity75.7 lcorrect
Hydraulic pressure120.7correct
Fuel tank capacity94.6 lcorrect

Frequently asked questions

How much power does the John Deere JD24 have?

The John Deere JD24 delivers 27.6 kW.

What engine does the John Deere JD24 have?

2,524 cm³ displacement.

How fast does the John Deere JD24 go?

Top speed is 11.3 km/h.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 13 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
