John Deere 862B Series II

Series: John Deere Elevating Motor Scraper

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 862B Series II, John Deere offers a model from the John Deere Elevating Motor Scraper series. The engine delivers 285.9 hp (199.8 kW), with a displacement of 10,143.6 cm³. Rated speed is 2,100 rpm. The wheelbase measures 6,842.8 mm. The tank holds 416 litres. The gearbox has 6 forward gears. There are also 1 reverse gears. The hydraulic tank holds 91.2 litres. The cooling system holds 52.2 litres. The oil fill is 34.1 litres. The electrical system runs on 24 V. Tyre size: 26,5-25. Rated output across the John Deere range ranges from 10.6 to 577.9 hp; the 862B Series II sits in the middle of that range with 285.9 hp. Its immediate neighbours are the 9120 280 Engine hp below it with 283.9 hp and the 744H High Lift above it with 286.9 hp. 2153 John Deere models across 96 series are on record. The model is listed under Mining equipment. 17 verified figures from 1 source are on file.

Technical data

Engine

Power	285.9 hp (199.8 kW)correct
Rated speed	2,100 rpmcorrect
Displacement	10,143.6 cm³correct
Aspiration	turbocharged and aftercooledcorrect
Coolant capacity	52.2 lcorrect
Engine oil capacity	34.1 lcorrect

Dimensions and weights

Length	11,100.8correct
Width	2,642.6correct
Wheelbase	6,842.8correct

Drivetrain and chassis

Gearbox type	planetarycorrect
Forward gears	6correct
Reverse gears	1correct
Tyre size	26.5-25correct
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	91.2 lcorrect
Fuel tank capacity	416 lcorrect

Frequently asked questions

How much power does the John Deere 862B Series II have?

The John Deere 862B Series II delivers 286 hp.

What engine does the John Deere 862B Series II have?

10,144 cm³ displacement.

What are the dimensions of the John Deere 862B Series II?

11,101 mm × 2,643 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
