John Deere 762B Series II

Series: John Deere Elevating Motor Scraper

Source: https://www.deere.ca/en/publications/the-landing/the-marshal

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 762B Series II belongs to the John Deere Elevating Motor Scraper series. The engine delivers 192.6 hp (134.2 kW), with a displacement of 8,128 cm³. Rated speed is 2,100 rpm. The wheelbase measures 6,211.8 mm. The tank holds 329.3 litres. The gearbox has 6 forward gears. There are also 1 reverse gears. The hydraulic tank holds 83.3 litres. The cooling system holds 34.1 litres. The oil fill is 28.8 litres. The electrical system runs on 24 V. Tyre size: 23,5-25. Rated output across the John Deere range ranges from 10.6 to 577.9 hp; the 762B Series II sits in the lower part of that range with 192.6 hp. Its immediate neighbours are the 748H below it with 191.6 hp and the 850C LGP above it with 194.7 hp. 2153 John Deere models across 96 series are on record. The model is listed under Mining equipment. 17 verified figures from 1 source are on file.

Technical data

Engine

Power	192.6 hp (134.2 kW)correct
Rated speed	2,100 rpmcorrect
Displacement	8,128 cm³correct
Aspiration	turbocharged and aftercooledcorrect
Coolant capacity	34.1 lcorrect
Engine oil capacity	28.8 lcorrect

Dimensions and weights

Length	10,061.4correct
Width	2,441.4correct
Wheelbase	6,211.8correct

Drivetrain and chassis

Gearbox type	planetarycorrect
Forward gears	6correct
Reverse gears	1correct
Tyre size	23.5-25correct
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	83.3 lcorrect
Fuel tank capacity	329.3 lcorrect

Frequently asked questions

How much power does the John Deere 762B Series II have?

The John Deere 762B Series II delivers 193 hp.

What engine does the John Deere 762B Series II have?

8,128 cm³ displacement.

What are the dimensions of the John Deere 762B Series II?

10,061 mm × 2,441 mm.
