Start › Wheel loaders › John Deere › 844K Z-Bar

John Deere 844K Z-Bar

Series: John Deere Wheel Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 844K Z-Bar from John Deere is part of the John Deere Wheel Loader series. The engine delivers 283.4 kW, has 6 cylinders, with a displacement of 13,502.9 cm³. Torque is 1,793.7 Nm. Rated speed is 1,600 rpm. The unladen weight is 32,037 kg. The wheelbase measures 3,700.3 mm. Ground clearance is 460.2 mm. The tank holds 553 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 900 rpm. The pump delivers 621.2 l/min. The hydraulic tank holds 244.2 litres. The cooling system holds 52.2 litres. The electrical system runs on 24 V. The engine fitted is the 6135H. Tier III certified. Tyre size: 29,5 R 25. The John Deere Wheel Loader series covers 120 models. Rated output within it ranges from 38.8 to 283.4 kW; the 844K Z-Bar sits at the top of that range with 283.4 kW. Its immediate neighbours are the 824K Z-Bar below it with 248.3 kW. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine model6135H, Tier III certifiedcorrect
Power283.4 kWcorrect
Rated speed1,600 rpmcorrect
Torque1,793.7correct
Speed at max. torque900 rpmcorrect
Cylinders6correct
Displacement13,502.9 cm³correct
AspirationTurbocharged charge air cooledcorrect
Coolant capacity52.2 lcorrect

Dimensions and weights

Wheelbase3,700.3correct
Ground clearance460.2correct
Unladen weight32,037 kgcorrect

Drivetrain and chassis

Gearbox typeCountershaft, powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size29.5 R 25correct
System voltage24 Vcorrect

Working data

Pump flow621.2 l/mincorrect
Hydraulic oil capacity244.2 lcorrect
Fuel tank capacity553 lcorrect

Other data

Height3,761.2correct

Where this model stands

Power-to-weight ratio: 8.8 kW/t (283 kW / 32 t)

Stronger than 95% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 844K Z-Bar have?

The John Deere 844K Z-Bar delivers 283 kW.

How much does the John Deere 844K Z-Bar weigh?

The unladen weight is 32,037 kg.

What engine does the John Deere 844K Z-Bar have?

6 cylinders, 13,503 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
