Start › Backhoe loaders › John Deere › 710K

John Deere 710K

Series: John Deere Loader Backhoe

Source: https://www.wirtgen-group.com/ocs/de-nl/john_deere/radlader-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 710K, John Deere offers a model from the John Deere Loader Backhoe series. The engine delivers 97 kW, with a displacement of 6,800.6 cm³. The engine comes from John Deere PowerTech. Rated speed is 2,000 rpm. The wheelbase measures 2,621.3 mm. Ground clearance is 356.6 mm. The tank holds 261.2 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. The pump delivers 196.8 l/min. The hydraulic tank holds 149.9 litres. Working pressure is 249.9 bar. The cooling system holds 34.1 litres. The electrical system runs on 12 V. The engine fitted is the E 6068HT079. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 30.6 to 97 kW; the 710K sits at the top of that range with 97 kW. Its immediate neighbours are the 710J below it with 91.7 kW. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine makeJohn Deere PowerTechcorrect
Engine modelE 6068HT079correct
Power97 kWcorrect
Rated speed2,000 rpmcorrect
Displacement6,800.6 cm³correct
Aspirationturbochargedcorrect
Coolant capacity34.1 lcorrect

Dimensions and weights

Wheelbase2,621.3correct
Ground clearance356.6correct

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
System voltage12 Vcorrect

Working data

Pump flow196.8 l/mincorrect
Hydraulic oil capacity149.9 lcorrect
Hydraulic pressure249.9correct
Fuel tank capacity261.2 lcorrect

Frequently asked questions

How much power does the John Deere 710K have?

The John Deere 710K delivers 97 kW.

What engine does the John Deere 710K have?

6,801 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
