John Deere 710C

Series: John Deere Loader Backhoe

Source: https://www.tractordata.com/farm-tractors/001/2/2/1227-john-

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 710C from John Deere is part of the John Deere Loader Backhoe series. The engine delivers 121.7 hp (85.8 kW), has 6 cylinders, with a displacement of 5,883 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,401.8 mm. Ground clearance is 356.6 mm. The tank holds 140.1 litres. The gearbox has 4 forward gears. There are also 2 reverse gears. The pump delivers 200.6 l/min. The hydraulic tank holds 151.4 litres. Working pressure is 175.8 bar. The cooling system holds 26.1 litres. The electrical system runs on 12 V. The engine fitted is the 6059T. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 43.6 to 121.7 hp; the 710C sits at the top of that range with 121.7 hp. Its immediate neighbours are the 510D below it with 101.4 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.

Technical data

Engine

Engine model6059Tcorrect
Power121.7 hp (85.8 kW)correct
Rated speed2,200 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
Coolant capacity26.1 lcorrect

Dimensions and weights

Wheelbase2,401.8correct
Ground clearance356.6correct

Drivetrain and chassis

Gearbox typepowershift transmission with modulated full power shifting between forward and reversecorrect
Forward gears4correct
Reverse gears2correct
System voltage12 Vcorrect

Working data

Pump flow200.6 l/mincorrect
Hydraulic oil capacity151.4 lcorrect
Hydraulic pressure175.8correct
Fuel tank capacity140.1 lcorrect

Frequently asked questions

How much power does the John Deere 710C have?

The John Deere 710C delivers 122 hp.

What engine does the John Deere 710C have?

6 cylinders, 5,883 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
