John Deere 544D

Series: John Deere Wheel Loader

Source: https://commons.wikimedia.org/wiki/File:John_Deere_544J_righ

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 544D belongs to the John Deere Wheel Loader series. The engine delivers 123.7 hp (85.8 kW), has 6 cylinders, with a displacement of 6,784.2 cm³. Torque is 477.2 Nm. Rated speed is 2,200 rpm. The unladen weight is 10,278.4 kg. The wheelbase measures 2,590.8 mm. Ground clearance is 438.9 mm. The tank holds 189.3 litres. The gearbox has 4 forward gears. There are also 2 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 186.2 l/min. The hydraulic tank holds 61.3 litres. The cooling system holds 23.1 litres. The electrical system runs on 12 V. The engine fitted is the 6-414T. Tyre size: 17,5-25. The John Deere Wheel Loader series covers 120 models. Rated output within it ranges from 55.8 to 286.9 hp; the 544D sits in the lower part of that range with 123.7 hp. Its immediate neighbours are the 544GTC below it with 121.7 hp and the 544 above it with 126.7 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine model6-414Tcorrect
Power123.7 hp (85.8 kW)correct
Rated speed2,200 rpmcorrect
Torque477.2correct
Speed at max. torque1,300 rpmcorrect
Cylinders6correct
Displacement6,784.2 cm³correct
Aspirationturbochargedcorrect
Coolant capacity23.1 lcorrect

Dimensions and weights

Wheelbase2,590.8correct
Ground clearance438.9correct
Unladen weight10,278.4 kgcorrect

Drivetrain and chassis

Gearbox typePower shift Planetarycorrect
Forward gears4correct
Reverse gears2correct
Tyre size17.5-25correct
System voltage12 Vcorrect

Working data

Pump flow186.2 l/mincorrect
Hydraulic oil capacity61.3 lcorrect
Fuel tank capacity189.3 lcorrect

Other data

Height3,072.4correct

Where this model stands

Power-to-weight ratio: 8.3 kW/t (86 kW / 10.3 t)

Stronger than 43% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the John Deere 544D have?

The John Deere 544D delivers 124 hp.

How much does the John Deere 544D weigh?

The unladen weight is 10,278 kg.

What engine does the John Deere 544D have?

6 cylinders, 6,784 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
