John Deere 510C

Series: John Deere Loader Backhoe

Source: http://www.mascus.com.tw/agriculture/%B6%FE%CA%D6-%C2%93%BA%

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere 510C belongs to the John Deere Loader Backhoe series. The engine delivers 96.3 hp (67.1 kW), has 4 cylinders, with a displacement of 4,522.8 cm³. Rated speed is 2,200 rpm. The wheelbase measures 2,100.1 mm. Ground clearance is 332.2 mm. The tank holds 143.8 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 132.5 l/min. The hydraulic tank holds 79.5 litres. Working pressure is 190 bar. The cooling system holds 16.3 litres. The electrical system runs on 12 V. The engine fitted is the 4045T. The John Deere Loader Backhoe series covers 57 models. Rated output within it ranges from 43.6 to 121.7 hp; the 510C sits in the upper part of that range with 96.3 hp. Its immediate neighbours are the 315SG below it with 93.8 hp and the 410E above it with 99.4 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model4045Tcorrect
Power96.3 hp (67.1 kW)correct
Rated speed2,200 rpmcorrect
Speed at max. torque1,300 rpmcorrect
Cylinders4correct
Displacement4,522.8 cm³correct
Aspirationturbochargedcorrect
Coolant capacity16.3 lcorrect

Dimensions and weights

Wheelbase2,100.1correct
Ground clearance332.2correct

Drivetrain and chassis

Gearbox type4-speed helical gear, synchromesh gearbox, collar shift transmission with hydraulic revcorrect
Forward gears4correct
Reverse gears4correct
System voltage12 Vcorrect

Working data

Pump flow132.5 l/mincorrect
Hydraulic oil capacity79.5 lcorrect
Hydraulic pressure190correct
Fuel tank capacity143.8 lcorrect

Frequently asked questions

How much power does the John Deere 510C have?

The John Deere 510C delivers 96.3 hp.

What engine does the John Deere 510C have?

4 cylinders, 4,523 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
